ASI - 3801 Series Straight Grab Bar – Peened
CALL FOR PRICING
ASI - 3801 Series Straight Grab Bar – Peened
Features include cover that snaps over mounting flange dimples to conceal screws and concealed mounting flange of 3-1/8″ (79 mm) O.D. diameter with 2 screw holes and 3 locking dimples; 1/8″ (3 mm) thick, type 304 stainless steel. Cover is type 304 stainless steel with a satin finish and 22 gauge, 3-3/16″ (81 mm) diameter.
Snap Flange (1-1/2″ O.D) Peened – Straight Grab Bar
Features
- Straight Grab Bar
- Snap Flange – cover snaps over mounting flange to conceal screws
- Type 304 Stainless Steel - Satin Finish
- Peened for better gripping
- Surface Mounted
- Concealed mounting flange of 3-1/8″ (79 mm) O.D. diameter with 2 screw holes and 3 locking dimples
- Mounting flange is 1/8″ (3 mm) thick, type 304 stainless steel
- Cover is type 304 stainless steel with a satin finish and 22 gauge, 3-3/16″ (81 mm) diameter
Available Sizes
- 18″ (457 mm) – 10-3801-18P
- 36″ (914 mm) – 10-3801-36P
- 42″ (1067 mm) – 3801-42P
Specifications
Series
3801 Series
Type
Straight Grab Bar – Peened
Dimensions
1-1⁄4″ (32 mm) O.D.
Construction
Type 304 Stainless Steel - Satin Finish
Surface
Peened
Mounting
Surface Mounted
Mounting Flange
Concealed mounting flange of 3-1/8″ (79 mm) O.D. diameter with 2 screw holes and 3 locking dimples; 1/8″ (3 mm) thick, type 304 stainless steel.
Cover
Type 304 stainless steel with a satin finish and 22 gauge, 3-3/16″ (81 mm) diameter.
Capacity
ASI grab bars are designed to meet and exceed 2010 ADA Accessibility Standards and ANSI A117.1. The fabricated product is designed to support a load in excess of 250 pounds (113.4 kg). Proper wall mounting, anchoring and an adequately sized fastener system are required to meet the specified loading requirements.
Finishes
- Peened
Installation
Use the grab bar as a template to locate and pre-drill the mounting holes. Install each flange with two appropriate #10 self-threading flat or oval head screws or another fastener system suitable for the wall conditions.
Appropriate anchoring and backing must be provided in accordance with applicable building requirements or the architect's plans before the wall is finished.
For 2010 ADA Accessibility Standards, the top of the grab bar should be installed between 33″ [840] minimum and 36″ [915] maximum Above Finished Floor (AFF).
ASI anchors are available separately and should be specified according to the grab bar and mounting conditions.
Related Items
ASI - 0477-SM Toilet Seat Cover Dispenser – Surface Mounted
CALL FOR PRICING
Please contact us by email or phone for pricing on this item.
ASI - 0030 Toilet Tissue Dispenser, Twin Hide-A-Roll – Surface Mounted
CALL FOR PRICING
Please contact us by email or phone for pricing on this item.
0030 Toilet Tissue Dispenser, Twin Hide-A-Roll – Surface Mounted
Holds two rolls up to 5 1/4″ (133 mm) diameter (1800 sheets). Top roll automatically drops in place when bottom roll is used up. Type 304 stainless steel cabinet and mechanism. Theft resistant spindles.
Stainless Steel Construction
Our heavy-duty items are made of high-quality 304 stainless steel, which is tough, durable, stain-resistant and easy to clean.
Tumbler Locks
Our tumbler locks provide convenience and security with an elegant look.
Safe Easy Dispensing
Dispensing and storage options vary, from single roll to multiple rolls or jumbo roll dispensers.
Features
- "Hide-A-Roll" dispenser holds two rolls
- Holds two rolls up to 5 1/4″ (133 mm) diameter
- 1800 sheet capacity
- Top roll automatically drops in place when bottom roll is used up
- Theft resistant spindles
- Tumbler lock
- Type 304 Stainless Steel - Satin Finish
- Surface Mounted
Specifications
Model
0030
Type
Toilet Tissue Dispenser, Twin Hide-A-Roll
Dimensions
6″ x 12″ x 6 1/2″ (152 x 305 x 165 mm)
Construction
Type 304 Stainless Steel - Satin Finish
Door
18 gauge Type 304 stainless steel
Cabinet Body & Dispensing Mechanism
22 gauge Type 304 stainless steel
Mounting
Surface Mounted
Capacity
Holds two rolls up to 5 1/4″ (133 mm) diameter (1800 sheets)
Finishes
- Type 304 Stainless Steel - Satin Finish
Operation & Maintenance
Reloading instructions are printed on graphic label inside door.
Bottom roll is depleted prior to top roll automatically dropping into lower position for use.
Empty rollers cannot be removed without key unlocking door.
Installation
Unit is surface mounted on wall or partition using four (4) 1/4″ x 1″ [M6 x 25] Philips pan-head self-threading screws (by others) through slots on rear wall into suitable wall preparation (by others).
Top two (2) mounting holes through back are "keyhole" slots for ease in hanging unit on pre-installed screws. Bottom two (2) mounting holes are horizontal slots for ease of adjustment.
For compliance with 2010 ADA Accessibility Standards and 2015 ABA Standards install unit with axis of bottom roller 15″ [381] min AFF (Above Finished Floor) to 48″ [1219] max AFF and centerline of dispenser shall be 7″ [178] min to 9″ [229] max. in front of toilet.
ASI - 7345-S Robe Hook (Double) – Surface Mounted, Satin Finish
CALL FOR PRICING
Please contact us by email or phone for pricing on this item.
7345-S Robe Hook (Double) – Surface Mounted, Satin Finish
4″ (102 mm) wide stainless steel bar forms hook at each end. Unit extends 2″ (51 mm) from wall. Hook is suitable for robes or clothing and small carry bags. Satin finish.
Features
- Double Hook
- Type 304 Stainless Steel - Satin Finish
- Surface Mounted
- 4″ (102 mm) wide stainless steel bar forms hook at each end
- Hook is suitable for robes or clothing and small carry bags
Specifications
Model
7345-S
Type
Robe Hook (Double)
Dimensions
4″ x 2″ x 2″ (102 x 51 x 51 mm)
Construction
Type 304 Stainless Steel - Satin Finish
Mounting
Surface Mounted
Finishes
- 7345-B – Bright Finish
- 7345-S – Satin Finish
Operation & Maintenance
Hook is suitable for a robe or clothing and small carry bags.
Installation
Surface mount unit on door back or wall using two (2) #10 self-threading screws (by others) through holes provided in mounting plate into suitable prepared mountings (by others) or other suitable mounting hardware (by others) to suit door or wall conditions. Hang post and flange assembly on mounting plate and tighten set screw to lock unit to plate.
For compliance with ICC/ANSI A-117.1-2003 and 2010 ADA Accessibility Standards, install unit with top of hook 48″ [1219] maximum Above Finished Floor (AFF) or 46″ [1168] max AFF if side reach access over an obstruction (e.g. vanity) with reach depth greater than 10″ [254] and less than 25″ [635] is only provided or 44″ [1118] max AFF if forward reach over an obstruction with reach depth greater than 20″ [508] and less than 25″ [635] is only provided.
For general utility, install hook with centerline of mounting plate 68″ [1727] AFF.
ASI - 7340-S Robe Hook (Single) – Surface Mounted, Satin Finish
CALL FOR PRICING
Please contact us by email or phone for pricing on this item.
7340-S Robe Hook (Single) – Surface Mounted, Satin Finish
Hook extends 2″ (51 mm) from wall and is suitable for a robe or clothing and small carry bags. Fabricated from stainless steel, satin finish.
Features
- Single Hook
- Type 304 Stainless Steel - Satin Finish
- Surface Mounted
- Hook extends 2" [51] from wall
- Hook is suitable for a robe or clothing and small carry bags
Specifications
Model
7340-S
Type
Robe Hook (Single)
Dimensions
2" [51] W x 2" [51] H x 2" [51] D
Construction
Type 304 Stainless Steel - Satin Finish
Mounting
Surface Mounted
Finishes
- 7340-B – Bright Finish
- 7340-S – Satin Finish
Operation and Maintenance
Hook is suitable for a robe or clothing and small carry bags.
Installation
Surface mount unit on door back or wall using two (2) #10 self-threading screws (by others) through holes provided in mounting plate into suitable prepared mountings (by others) or other suitable mounting hardware (by others) to suit door or wall conditions.
Hang post and flange assembly on mounting plate and tighten set screw to lock unit to plate.
For compliance with ICC/ANSI A-117.1-2003 and 2010 ADA Accessibility Standards, install unit with top of hook 48" [1219] maximum Above Finished Floor (AFF) or 46" [1168] max AFF if side reach access over an obstruction (e.g. vanity) with reach depth greater than 10" [254] and less than 25" [635] is only provided or 44" [1118] max AFF if forward reach over an obstruction with reach depth greater than 20" [508] and less than 25" [635] is only provided.
For general utility, install hook with centerline of mounting plate 68" [1727] AFF.
