Electric Strikes
Electric Strikes from HES.
478-32D - Trine Electric Strikes
$46.80
478-32D
3000 Series Faceplate, 4-7/8" x 1-1/4", Satin Stainless Steel
Product Specs
Vendor Trine Access Technology
Manufacturer Trine
SKU 478-32D
UID TRI10047832D
Installation Commercial
Unit of Measure Each
Base Material Stainless Steel
Limited Warranty 1 Year
Finish
630/US32D
Finish Description Satin Stainless Steel
Finish Family Matte Silver
Technical Specs
Faceplate Size 4-7/8" x 1-1/4"
Product Type Electric Strikes
INSTALLATION CHALLENGE LEVEL
Easy
Anyone who can read instructions and use basic tools can install this product.
4800F-32D - Trine Electric Strike
$434.25
4800F-32D
Rim Exit Strike, 3/4" Surface Mount, 12/24VDC, 12-24VAC, Fail Secure, Satin Stainless Steel
Product Specs
Vendor Trine Access Technology
Manufacturer Trine
SKU 4800F-32D
UID TRI1004800F32D
Installation Commercial
Unit of Measure Each
Base Material Stainless Steel
Limited Warranty 1 Year
Finish
Finish
630/US32D
Finish Description Satin Stainless Steel
Finish Family Matte Silver
Technical Specs
Function Fail Safe/Fail Secure
Operating Voltage 12/24 VDC
Amp Draw .509-.405-.215 / .556.253
Configuration Centered
Faceplate Size 9" x 1-3/4"
Product Type Electric Strikes
INSTALLATION CHALLENGE LEVEL
Easy
Anyone who can read instructions and use basic tools can install this product
4850-32D - Trine Electric Strike
$434.25
4850-32D
Rim Exit Strike, 1/2" Surface Mount, 12/16/24DC, 12/16/24DC, Fail Safe/Secure, Satin Stainless Steel
Product Specs
Vendor Trine Access Technology
Manufacturer Trine
SKU 4850-32D
UID TRI100485032D
Installation Commercial
Unit of Measure Each
Base Material Stainless Steel
Limited Warranty 1 Year
Finish
Finish
630/US32D
Finish Description Satin Stainless Steel
Finish Family Matte Silver
Technical Specs
Function Fail Safe/Fail Secure
Operating Voltage 12/24 VDC
Amp Draw .509-.405-.215 / .556.253
Configuration Centered
Faceplate Size 9" x 1-3/4"
Product Type Electric Strikes
INSTALLATION CHALLENGE LEVEL
Easy
Anyone who can read instructions and use basic tools can install this product
7100 Series Adams Rite Electric Strikes
$213.00
Electric Strike, Electrically Unlocked (Fail Secure), For Hollow Metal or Wood Applications, 4-7/8" x 1-1/4" Flat Faceplate with Square Corners, 12VAC, Satin Aluminum Clear Anodized
Product Specs
Vendor Assa Abloy
Manufacturer Adams Rite
SKU 7170-340-628-00
UID ADA1007170340628
Installation Commercial
Unit of Measure Each
Application Aluminum, Metal or Wood Applications
Finish
628/US28
Finish Description Satin Aluminum Clear Anodized
Finish Family Matte Silver
Technical Specs
Function Fail Secure
Operating Voltage 12 VAC
Amp Draw 1.42 Amps
Faceplate Size 4-7/8" x 1-1/4"
Faceplate Shape Flat Face, Square Corners
Product Type Electric Strikes
7100 Electric Strikes
Designed for use with Adams Rite deadlatches or cylindrical locksets with 1/2" to 5/8" latchbolt projection.
For use in aluminum, hollow metal, or wood applications — remote electrical control of any door equipped with an Adams Rite 4500, 4700 (discontinued), or 4900 Deadlatch or cylindrical lockset with 1/2" [12.7 mm] to 5/8" [15.9 mm] latchbolt projection. Electrical actuation unlocks the keeper, releasing the latchbolt so the door may be opened without operating the latch itself.
- Fail-Safe/Fail-Secure: Field convertible from one mode to the other. However, AC intermittent solenoid must not be used continuously in either.
- Case: Approximately 1” x 3-3/8” x 1-5/8” deep.
- Strike Lip: Basic 7100 strike has lip of proper length for 1-3/4” thick door that closes flush with jamb edge. Where door thickness or jamb shape differs from this standard relationship, lip extension kits are available, specified by last dash number. Not available on 7101.
- Strike Opening: 5/8” x 1-7/16” x 1/2” deep. Bolt retainer jaw is stainless steel. Strike accepts bolt of any Adams Rite 4500, 4700 (discontinued), or 4900 Deadlatch or cylindrical latches.
- Faceplate: Measures 1-1/4” x 4-7/8”. 7100 has flat faceplate; 7101 is radiused to match nose on inactive leaf in a pair of narrow stile glass doors. Available in a wide range of architectural finishes.
- Voltage: Available in 12 or 24 volt AC and DC. DC continuous units are silent, AC intermittent units “buzz” on operation.
INSTALLATION CHALLENGE LEVEL
Easy
Anyone who can read instructions and use basic tools can install this product.
7800-630 Adams Rite Electric Strikes for Rim exit device
$531.75
7800-630
Fail Safe/Fail Secure, Complete 12/24VDC Electric Strike, Surface Mounted, Grade 1, 1/2" Thick Strike Body, Non-Handed, Satin Stainless Steel
Product Specs
Vendor Assa Abloy
Manufacturer Adams Rite
SKU 7800-630
UID ADA1007800630
Grade Grade 1
Installation Commercial
Unit of Measure Each
Finish
630/US32D
Finish Description Satin Stainless Steel
Finish Family Matte Silver
Technical Specs
Function Fail Safe/Fail Secure
Operating Voltage 12/24 VDC
Amp Draw .45 @ 12V .25 @ 24V
Keeper Size Starwheel Keeper
For Use With Rim Exit Devices
Faceplate Depth 1/2"
Holding Force 1500 lbs.
Frame Application Metal or Wood
Product Type Electric Strikes
7800 Series Electric Strikes
The Adams Rite 7800 Electric Strike is intended for use with Adams Rite rim exit devices with a Starwheel/Interlocking latchbolt (8800 & 8700 Series, EX88), and in aluminum, hollow metal or wood applications.
This low-profile, non-handed, surface-mounted electric strike features an ultra-compact design and adjustable stainless steel keepers with over 1,500 pounds [680.4 kg] of holding force in fail-secure mode. This strike boasts electrical remote control, allowing door to open without actuation of an exit device. Internally mounted dual solenoid operates on 12 or 24 VDC power.
Features:
- Strike Dimensions: 1-13/4" x 9" x 9/16" deep [44.5 mm x 229 mm x 14.2 mm deep]
- Strike Opening: Bolt retaining keeper is stainless steel. 1" x 1-1/2" x 1/2" deep [24.4 mm x 38.1mm x 12.7 mm deep]. Strike only accepts Starwheel/Interlocking latching mechanism.
- Faceplate: Not separate.1-3/4" x 9-1/64" x 9/16" [44.5 mm x 229 mm x 14.2 mm deep]
- Compatibility: Accommodates Starwheel/Interlocking latching mechanism of Adams Rite 8800, 8700, EX88 Series Rim Exit Devices.
- Standard Package: Individually boxed with 1/16" and 1/8"spacer plates, mounting screws and installation instructions. Spacer Plates included to accommodate varying door gaps. Screws for wood applications not provided.
Electrical:
- Voltage: Field selectable, dual voltage, 12 or 24 VDC.
-
Current Draw:
0.45A at 12 VDC
0.25A at 24 VDC - Fail Safe | Fail Secure: Field selectable fail safe/fail secure
Options and Accessories:
- Ships standard with one 1/16" and 1/8"spacer plate. Units ordered in 613E, 628E, 630, & BSP finishes will be made of stainless steel to match. All other finishes will receive black stainless steel spacers. Additional spacer plates can be ordered separately.
- Available with two monitoring options: Form 'C' monitoring switches to indicate when the latchbolt is engaged in the strike jaws and a locked/unlocked solenoid status (M). Latchbolt monitor (L)
- ELX-ElectroLynx® Adapter: Connects Adams Rite electrified products to ElectroLynx system
Easy
Anyone who can read instructions and use basic tools can install this product.
HES 5000 Series Electric Strike
$203.00
The 5000 series is a compact, high performance electric strike designed for low profile openings where there is limited space behind the jamb. Its strength is derived from a unique keeper pin locking design, enabling the 5000 to exceed the ratings of the frame, door and locking hardware. This field selectable fail secure/fail safe unit is easy to install and accommodates latch bolts up to 5/8" throw.
Features
- Tamper resistant
- Static strength 1,500 lbs.
- Dynamic strength 70 ft-lbs.
- Endurance 500,000 cycles
- Field selectable fail secure/ fail safe
- Dual voltage 12 or 24 VDC/VAC
- Non-handed
- Internally mounted solenoid
- Accommodates 1/2" - 5/8" latchbolt (5/8" with 1/8" door gap)
- Strike body depth 1-1/16"
- Plug-in connector
- Trim enhancer included
- Five year limited warranty
Specs
- UL 1034 burglary-resistant listed and suitable for outdoor use
- UL 294 (6th Edition) listed
- ANSI/BHMA A156.31, Grade 1
- MEA New York City accepted
- Patent #5,934,720
Finishes
Satin Stainless Steel 630/US32D
Installation Challenge Level
Easy
Anyone who can read instructions and use basic tools can install this product.
HES 9400 Series Electric Strike
$451.00
The 9400 series is a slim-line, surface mounted electric strike designed to accommodate rim exit devices with a 1/2" Pullman latch. All components are completely encased within its 1/2" thick stainless steel housing, so no cutting on the frame is required for installation. Simply place the electric strike on the surface of the frame, align it with the exit latchbolt, and install.
The 9400 ships with a 1/8" spacer plate to accommodate varying door gaps. The 9400 exceeds Grade-1 standards for strength and performance. It is field selectable for fail secure and fail safe operation, and for 12 or 24VDC. The 9400 features a smooth cover to conceal the mounting screws and provide a sleek surface for superior looks.
Features
- Installs in metal and wood frames
- Completely surface mounted
- Decorative cover for sleek new look
- Stainless steel construction
- Tamper resistant
- Static strength 1,500 lbs.
- Dynamic strength 70 ft-lbs.
- Endurance 500,000 cycles
- 1/8" spacer plate included
- Field selectable fail safe/fail secure
- Dual voltage 12 or 24 VDC
- Horizontal adjustment
- Non-handed
- Internally mounted solenoid
- Accommodates up to 1/2" Pullman latch
- Five year limited warranty
Specs
- UL 1034 burglary-resistant listed and suitable for outdoor use
- UL 294 (6th Edition) listed
- ANSI/BHMA, A156.31 Grade 1 (#E09731, #E09732, #E09373)
- RoHS Compliant
- Patent 6,390,520;8,454,063
- Patent Pending
Frame application
- Metal
- Wood
Electrical
- .45 Amps at 12VDC continuous duty
- .25 Amps at 24VDC continuous duty
Finishes
Satin Stainless Steel 630/US32D
Installation Challenge Level
Easy
Anyone who can read instructions and use basic tools can install this product.
