Vision Lite Kits & Louvers
Vision Lite Kits (door windows), Lite Kits with Tempered Glass, and Door Louvers from Air Louvers. Our products meet the requirements of the Buy American Act.
Air Louvers Lite Kit with Tempered Glass 12" x 12"
$135.00
Air Louvers Beveled Vision Lite VLFEZ Temp Pak
For Offices, Schools, Hospitals and more, Air Louvers Vision Lites are made of high quality material for long lasting durability and dependability. This kit's tempered glass is used to retain and direct heat preventing the spread of fire.
Features
- Complete Individually-Packaged Vision Lite Kit for 1-3/4" Doors
- Countersunk mounting holes leaves corridor side of frame free of fasteners for aesthetic and security purposes
- Tempered Glass is CAT II Impact-rated
- Glazing Tape Applied
Specs
- 20 gauge CRS frame
- 1-1/4" trim, with mitered and welded corners
- Continuous glass retainer
- Countersunk mounting holes
- #8 x 1" flathead phillips SMS included
- When installed in properly rated and approved fire door, ratings up to 3 hours can be achieved, depending on the glazing used. See glazing ratings for maximum exposed area. Tested and Listed for UL 10C and Criteria of UBC 7-2 Positive Pressure.
Finishes
Mineral Bronze Powder Coat Finish
Installation Challenge Level
Challenging
Recommended for Experienced Installers, but it's not rocket science.
Instructions & Files
Air Louvers Lite Kit with Tempered Glass 6" x 27"
$176.50
Air Louvers Beveled Vision Lite VLFEZ Temp Pak
For Offices, Schools, Hospitals and more, Air Louvers Vision Lites are made of high quality material for long lasting durability and dependability. This kit's tempered glass is used to retain and direct heat preventing the spread of fire.
Features
- Complete Individually-Packaged Vision Lite Kit for 1-3/4" Doors
- Countersunk mounting holes leaves corridor side of frame free of fasteners for aesthetic and security purposes
- Tempered Glass is CAT II Impact-rated
- Glazing Tape Applied
Specs
- 20 gauge CRS frame
- 1-1/4" trim, with mitered and welded corners
- Continuous glass retainer
- Countersunk mounting holes
- #8 x 1" flathead phillips SMS included
- When installed in properly rated and approved fire door, ratings up to 3 hours can be achieved, depending on the glazing used. See glazing ratings for maximum exposed area. Tested and Listed for UL 10C and Criteria of UBC 7-2 Positive Pressure.
Finishes
Mineral Bronze Powder Coat Finish
Installation Challenge Level
Challenging
Recommended for Experienced Installers, but it's not rocket science.
Instructions & Files
Air Louvers Vision Lite Kit 12" x 12"
$91.50
Air Louvers Beveled Vision Lite Kit VLFEZ
For Offices, Schools, Hospitals And more, Air Louvers Vision Lites are made of high quality material for long lasting durability and dependability. Does not include glazing. For kits including tempered glass, see Air Louvers Beveled Vision Lite VLFEZ Temp Pak.
Features
- Vision Lite Kit for 1-3/4" Doors
- Countersunk mounting holes leaves corridor side of frame free of fasteners for aesthetic and security purposes
Specs
- 20 gauge CRS frame
- 1-1/4" trim, with mitered and welded corners
- Continuous glass retainer
- Countersunk mounting holes
- #8 x 1" flathead phillips SMS included
- When installed in properly rated and approved fire door, ratings up to 3 hours can be achieved, depending on the glazing used. See glazing ratings for maximum exposed area. Tested and Listed for UL 10C and Criteria of UBC 7-2 Positive Pressure.
Finishes
Mineral Bronze Powder Coat Finish
Installation Challenge Level
Challenging
Recommended for Experienced Installers, but it's not rocket science.
Instructions & Files
Air Louvers Vision Lite Kit 6" x 27"
$116.00
Air Louvers Beveled Vision Lite Kit VLFEZ
For Offices, Schools, Hospitals And more, Air Louvers Vision Lites are made of high quality material for long lasting durability and dependability. Does not include glazing. For kits including tempered glass, see Air Louvers Beveled Vision Lite VLFEZ Temp Pak.
Features
- Vision Lite Kit for 1-3/4" Doors
- Countersunk mounting holes leaves corridor side of frame free of fasteners for aesthetic and security purposes
Specs
- 20 gauge CRS frame
- 1-1/4" trim, with mitered and welded corners
- Continuous glass retainer
- Countersunk mounting holes
- #8 x 1" flathead phillips SMS included
- When installed in properly rated and approved fire door, ratings up to 3 hours can be achieved, depending on the glazing used. See glazing ratings for maximum exposed area. Tested and Listed for UL 10C and Criteria of UBC 7-2 Positive Pressure.
Finishes
Mineral Bronze Powder Coat Finish
Installation Challenge Level
Challenging
Recommended for Experienced Installers, but it's not rocket science.
Instructions & Files
Air Louvers Vision Lite Kit 24" x 30"
$133.60
Air Louvers Beveled Vision Lite Kit VLFEZ
For Offices, Schools, Hospitals And more, Air Louvers Vision Lites are made of high quality material for long lasting durability and dependability. Does not include glazing. For kits including tempered glass, see Air Louvers Beveled Vision Lite VLFEZ Temp Pak.
Features
- Vision Lite Kit for 1-3/4" Doors
- Countersunk mounting holes leaves corridor side of frame free of fasteners for aesthetic and security purposes
Specs
- 20 gauge CRS frame
- 1-1/4" trim, with mitered and welded corners
- Continuous glass retainer
- Countersunk mounting holes
- #8 x 1" flathead phillips SMS included
- When installed in properly rated and approved fire door, ratings up to 3 hours can be achieved, depending on the glazing used. See glazing ratings for maximum exposed area. Tested and Listed for UL 10C and Criteria of UBC 7-2 Positive Pressure.
Finishes
Mineral Bronze Powder Coat Finish
Installation Challenge Level
Challenging
Recommended for Experienced Installers, but it's not rocket science.
Instructions & Files
Air Louvers 700A Door Louver 12" x 12"
$128.10
Two Rows of Inverted Split "Y" Blades Louver with Two-Piece Design for Wood or Metal Doors.
Features
- Free Flow Area: 50% free area
Specs
- Material: 18 gauge CRS frame and blades
- Construction: Louvers & Frame: 2 rows of inverted split "Y" blades at 1" intervals are attached by interlocking construction to the 3/4" deep welded frame. 1-1/4" trim, with mitered and welded corners and countersunk mounting holes. Non-vision Construction. Louver frame is screwed into door from 2 sides.
- Door: Minimum 1-3/8" thick door
- Fasteners: Phillips head screws #8 x 3/4"
Finishes
Mineral Bronze Powder Coat Finish
Installation Challenge Level
Challenging
Recommended for Experienced Installers, but it's not rocket science.
Instructions & Files
Air Louvers 700A Door Louver 18" x 12"
$138.00
Two Rows of Inverted Split "Y" Blades Louver with Two-Piece Design for Wood or Metal Doors.
Features
- Free Flow Area: 50% free area
Specs
- Material: 18 gauge CRS frame and blades
- Construction: Louvers & Frame: 2 rows of inverted split "Y" blades at 1" intervals are attached by interlocking construction to the 3/4" deep welded frame. 1-1/4" trim, with mitered and welded corners and countersunk mounting holes. Non-vision Construction. Louver frame is screwed into door from 2 sides.
- Door: Minimum 1-3/8" thick door
- Fasteners: Phillips head screws #8 x 3/4"
Finishes
Mineral Bronze Powder Coat Finish
Installation Challenge Level
Challenging
Recommended for Experienced Installers, but it's not rocket science.
Instructions & Files
Air Louvers 700A Door Louver 24" x 12"
$154.50
Two Rows of Inverted Split "Y" Blades Louver with Two-Piece Design for Wood or Metal Doors.
Features
- Free Flow Area: 50% free area
Specs
- Material: 18 gauge CRS frame and blades
- Construction: Louvers & Frame: 2 rows of inverted split "Y" blades at 1" intervals are attached by interlocking construction to the 3/4" deep welded frame. 1-1/4" trim, with mitered and welded corners and countersunk mounting holes. Non-vision Construction. Louver frame is screwed into door from 2 sides.
- Door: Minimum 1-3/8" thick door
- Fasteners: Phillips head screws #8 x 3/4"
Finishes
Mineral Bronze Powder Coat Finish
Installation Challenge Level
Challenging
Recommended for Experienced Installers, but it's not rocket science.
Instructions & Files
Air Louvers 700A Door Louver 24" x 24"
$213.90
Two Rows of Inverted Split "Y" Blades Louver with Two-Piece Design for Wood or Metal Doors.
AVAILABILITY: CALL FOR SHIPPING
Features
- Free Flow Area: 50% free area
Specs
- Material: 18 gauge CRS frame and blades
- Construction: Louvers & Frame: 2 rows of inverted split "Y" blades at 1" intervals are attached by interlocking construction to the 3/4" deep welded frame. 1-1/4" trim, with mitered and welded corners and countersunk mounting holes. Non-vision Construction. Louver frame is screwed into door from 2 sides.
- Door: 1-3/4" thick door
- Fasteners: Phillips head screws #8 x 3/4"
Finishes
Mineral Bronze Powder Coat Finish
Installation Challenge Level
Challenging
Recommended for Experienced Installers, but it's not rocket science.
Instructions & Files
800 Series – Standard Inverted “Y” Blade Louver - 1 3/4" Thick Door
$94.00
Categories: Door Louver , Interior -Non Fire rated
Most popular louver for Class A buildings is easy to install and provides 50% free area for good ventilation through doors. Inverted Y blades with 1″ spacing do not allow vision though the louver. When ordered with the self-attaching A1 frame option with mitered corners, the corridor side is free of fasteners.
Product Specifications
Finishes
Mineral Bronze Powder Coat Finish
Frame and Blades: Cold rolled steel, galvanneal, zinc-plated or stainless steel.
Standard Finish: Powder coat bronze on steel or 304 stainless with #4 finish.
Construction: 1″ depth louvers are mechanically attached to the sturdy welded frame.
Mounting Options:
1-3/4″ Door – A1, CORE, A, C
1-3/8″ to 1-5/8″ Door – CORE, A, C - (CALL FOR PRICING AND AVAILABILITY)
- Louver installation instructions (PDF)
-
Installation Challenge Level
Challenging
Recommended for Experienced Installers, but it's not rocket science.Submittal Sheet:
