Locks
Standard and Heavy Duty Commercial Door Cylindrical and Mortise Locksets, Deadbolts, and Keyless Door Locks from PDQ, Alarm Lock, and Simplex. Our products meet the requirements of the Buy American Act.
PDQ Cylindrical Lock - SD126 Passage
$70.00
PDQ SD series grade 2 lever set for commercial doors features unique through bolt installation for added security and durability and is UL listed A label for single swing doors.
The SD126 is a Passage function lock, where the latch bolt is operated by the lever from either side at all times. There is no locking function.
- Non keyed
- Latch bolt operated by lever from either side at all times
We also offer the SD Series Cylindrical Lock in several other functions - Entrance/Office, Privacy, and Storeroom. Compare Functions.
Features
- Listed by UL 10C / UBC 7-2 (1997) positive pressure, for single doors up to 4’0” x 8’0”.
- Certified to ANSI/BHMA A156.2–1996, Series 4000, Grade 2.
- Assembled in USA, meeting the requirements of the Buy American Act
- Lifetime Manufacturer's Limited Warranty
Specs
- FOR DOORS: 1-3/8" to 1-3/4" thick.
- DOOR PREP: Fits standard 161 door prep (2 1/8" hole x 2 3/4" backset). Through-door through-bolting. Through-bolts removable if desired.
- BACKSET: 2-3/4" is standard.
- FRONT: 2-1/4" x 1-1/8" for 2-3/4" backset. Stainless steel or wrought brass.
- STRIKE: 4-7/8" x 1-1/4" (ASA).
- LATCHBOLT: 1/2" throw. Adjustable front for flat or beveled doors.
- HAND: Non-handed.
- TRIM: Zinc diecast levers/wrought brass rose.
Finishes
Satin Chrome 626/US26D
Installation Challenge Level
Challenging
Recommended for Experienced or Professional Installers.
PDQ Cylindrical Lock - SD176 Privacy
$80.00
PDQ SD series grade 2 lever set for commercial doors features unique through bolt installation for added security and durability and is UL listed A label for single swing doors.
The SD176 is a Privacy function lock which features push-button locking. The lock can be opened from the outside with an emergency release. The inside push button can be released by turning the inside lever.
- Non keyed
- Latch bolt operated by lever from either side or emergency release in outside lever
- Outside lever locked by push button on inside
- Outside lever unlocked by emergency release from outside, rotating inside lever, or closing door
We also offer the SD Series Cylindrical Lock in several other functions - Entrance/Office, Storeroom and Passage. Compare Functions.
Features
- Listed by UL 10C / UBC 7-2 (1997) positive pressure, for single doors up to 4’0” x 8’0”.
- Certified to ANSI/BHMA A156.2–1996, Series 4000, Grade 2.
- Assembled in USA, meeting the requirements of the Buy American Act
- Lifetime Manufacturer's Limited Warranty
- Cylinder(s) included
Specs
- FOR DOORS: 1-3/8" to 1-3/4" thick.
- DOOR PREP: Fits standard 161 door prep (2 1/8" hole x 2 3/4" backset). Through-door through-bolting. Through-bolts removable if desired.
- BACKSET: 2-3/4" is standard.
- FRONT: 2-1/4" x 1-1/8" for 2-3/4" backset. Stainless steel or wrought brass.
- STRIKE: 4-7/8" x 1-1/4" (ASA).
- LATCHBOLT: 1/2" throw. Adjustable front for flat or beveled doors.
- HAND: Non-handed.
- TRIM: Zinc diecast levers/wrought brass rose.
Finishes
Satin Chrome 626/US26D
Installation Challenge Level
Challenging
Recommended for Experienced or Professional Installers.
PDQ Cylindrical Lock - SD115 Storeroom
$85.00
PDQ SD series grade 2 lever set for commercial doors features unique through bolt installation for added security and durability and is UL listed A label for single swing doors.
The SD115 is a Storeroom function lock, where the latch bolt is operated by a key outside and the lever from the inside. The outside lever is rigid.
- Latch bolt operated from outside by key, inside by lever
- Outside lever always fixed
- Inside lever always free
- Deadlocking (guarded) latch bolt all times
We also offer the SD Series Cylindrical Lock in several other functions - Entrance/Office, Privacy, and Passage. Compare Functions.
Features
- Listed by UL 10C / UBC 7-2 (1997) positive pressure, for single doors up to 4’0” x 8’0”.
- Certified to ANSI/BHMA A156.2–1996, Series 4000, Grade 2.
- Assembled in USA, meeting the requirements of the Buy American Act
- Lifetime Manufacturer's Limited Warranty
- Cylinder(s) included
Specs
- FOR DOORS: 1-3/8" to 1-3/4" thick.
- DOOR PREP: Fits standard 161 door prep (2 1/8" hole x 2 3/4" backset). Through-door through-bolting. Through-bolts removable if desired.
- BACKSET: 2-3/4" is standard.
- FRONT: 2-1/4" x 1-1/8" for 2-3/4" backset. Stainless steel or wrought brass.
- STRIKE: 4-7/8" x 1-1/4" (ASA).
- LATCHBOLT: 1/2" throw. Adjustable front for flat or beveled doors.
- HAND: Non-handed.
- TRIM: Zinc diecast levers/wrought brass rose.
- KEYS: Two change keys per lock.
Finishes
Satin Chrome 626/US26D
Installation Challenge Level
Challenging
Recommended for Experienced or Professional Installers.
PDQ Cylindrical Lock - SD116 Entrance/Office
$85.00
PDQ SD series grade 2 lever set for commercial doors features unique through bolt installation for added security and durability and is UL listed A label for single swing doors.
The SD116 is an Entrance/Office function lock, where the door is unlocked by a key from the outside when the outer lever is locked by a turn-button on the inside lever. The inside lever is always unlocked.
- Latch bolt operated by lever from either side or key in outside lever
- Outside lever locked by push/turn button on inside
- When outside lever is locked by push button on inside – key from outside,
or rotating inside lever unlocks outside lever - When outside lever is locked by pushing and turning the button on the inside,
key from outside or rotating inside lever retracts latch but does not unlock outside lever - Deadlocking (guarded) latch bolt
We also offer the SD Series Cylindrical Lock in several other functions - Privacy, Storeroom,and Passage. Compare Functions.
Features
- Listed by UL 10C / UBC 7-2 (1997) positive pressure, for single doors up to 4’0” x 8’0”.
- Certified to ANSI/BHMA A156.2–1996, Series 4000, Grade 2.
- Assembled in USA, meeting the requirements of the Buy American Act
- Lifetime Manufacturer's Limited Warranty
- Cylinder included
Specs
- FOR DOORS: 1-3/8" to 1-3/4" thick.
- DOOR PREP: Fits standard 161 door prep (2 1/8" hole x 2 3/4" backset). Through-door through-bolting. Through-bolts removable if desired.
- BACKSET: 2-3/4" is standard.
- FRONT: 2-1/4" x 1-1/8" for 2-3/4" backset. Stainless steel or wrought brass.
- STRIKE: 4-7/8" x 1-1/4" (ASA).
- LATCHBOLT: 1/2" throw. Adjustable front for flat or beveled doors.
- HAND: Non-handed.
- TRIM: Zinc diecast levers/wrought brass rose.
- KEYS: Two change keys per lock.
Finishes
Satin Chrome 626/US26D
Installation Challenge Level
Challenging
Recommended for Experienced or Professional Installers.
PDQ Extremely Heavy Duty Cylindrical Lock - XGT126 Passage
$189.00
US made, this line of grade 1 door locks gives you the best in security, durability, and cost. The XGT is able to withstand over 3,000 in. lbs. of torque resistance on its lever trim.
The XGT126 is a Passage function lock, where the latch bolt is operated by the lever from either side at all times. There is no locking function.
- Non keyed
- Latchbolt operated by lever from either side at all times
We also offer the XGT Series Cylindrical Lock in several other functions - Entrance/Office, Privacy, Storeroom and Classroom. Compare Functions.
Features
- ANSI Grade 1 Extremely Heavy Duty cylindrical door lock
- Exceeds 3,000 in lbs. of torque resistance
- High Strength stainless steel investment cast spindle. Heavy gauge steel mounting plates.
- Door Situation: Fits left, right wood/metal swing doors
- Architectural Finish
- Assembled in USA, meeting the requirements of the Buy American Act
- Lifetime Manufacturer's Limited Warranty
Specs
- FOR DOORS: 1-3/4" to 2-1/4" thick. Factory adjusted for 1-3/4"
- DOOR PREP: Fits standard 161 door prep. Through-door thru-bolting.
- BACKSET: 2-3/4" only. Guarded
- FRONT: 2-1/4" x 1-1/8". Beveled 1/8" on 2"
- STRIKE: 4-7/8" x 1-1/4"(ASA).
- LATCHBOLT: 9/16" Throw. Adjustable front for flat or beveled doors.
- HAND: Non-handed.
- TRIM: Zinc diecast levers/wrought brass rose.
Finishes
Satin Chrome 626/US26D
Installation Challenge Level
Challenging
Recommended for Experienced or Professional Installers.
PDQ Extremely Heavy Duty Cylindrical Lock - XGT176 Privacy
$205.00
PDQ XGT Series Heavy Duty Cylindrical Lock
US made, this line of grade 1 door locks gives you the best in security, durability, and cost. The XGT is able to withstand over 3,000 in. lbs. of torque resistance on its lever trim.
The XGT176 is a Privacy function lock which features push-button locking. The lock can be opened from the outside with an emergency release. The inside push button can be released by turning the inside lever.
- Non keyed
- Latchbolt operated by lever from either side or emergency release in outside lever
- Outside lever locked by push button on inside
- Outside lever unlocked by emergency release from outside, rotating inside lever, or closing door
We also offer the XGT Series Cylindrical Lock in several other functions - Entrance/Office, Storeroom, Classroom and Passage. Compare Functions.
Features
- ANSI Grade 1 Extremely Heavy Duty cylindrical door lock
- Exceeds 3,000 in lbs. of torque resistance
- High Strength stainless steel investment cast spindle. Heavy gauge steel mounting plates.
- Door Situation: Fits left, right wood/metal swing doors
- Architectural Finish
- Assembled in USA, meeting the requirements of the Buy American Act
- Lifetime Manufacturer's Limited Warranty
Specs
- FOR DOORS: 1-3/4" to 2-1/4" thick. Factory adjusted for 1-3/4"
- DOOR PREP: Fits standard 161 door prep. Through-door thru-bolting.
- BACKSET: 2-3/4" only. Guarded
- FRONT: 2-1/4" x 1-1/8". Beveled 1/8" on 2"
- STRIKE: 4-7/8" x 1-1/4"(ASA).
- LATCHBOLT: 9/16" Throw. Adjustable front for flat or beveled doors.
- HAND: Non-handed.
- TRIM: Zinc diecast levers/wrought brass rose.
Finishes
Satin Chrome 626/US26D
Installation Challenge Level
Challenging
Recommended for Experienced or Professional Installers.
PDQ Extremely Heavy Duty Cylindrical Lock - XGT115 Storeroom
$218.00
US made, this line of grade 1 door locks gives you the best in security, durability, and cost. The XGT is able to withstand over 3,000 in. lbs. of torque resistance on its lever trim.
The XGT115 is a Storeroom function lock, where the latch bolt is operated by a key outside and the lever from the inside. The outside lever is rigid.
- Latchbolt operated by inside lever or key in outside lever
- Outside lever always fixed
We also offer the XGT Series Cylindrical Lock in several other functions - Entrance/Office, Privacy, Classroom and Passage. Compare Functions.
Features
- ANSI Grade 1 Extremely Heavy Duty cylindrical door lock
- Exceeds 3,000 in lbs. of torque resistance
- High Strength stainless steel investment cast spindle. Heavy gauge steel mounting plates.
- Door Situation: Fits left, right wood/metal swing doors
- Architectural Finish
- Assembled in USA, meeting the requirements of the Buy American Act
- Lifetime Manufacturer's Limited Warranty
Specs
- FOR DOORS: 1-3/4" to 2-1/4" thick. Factory adjusted for 1-3/4"
- DOOR PREP: Fits standard 161 door prep. Through-door thru-bolting.
- BACKSET: 2-3/4" only. Guarded
- FRONT: 2-1/4" x 1-1/8". Beveled 1/8" on 2"
- STRIKE: 4-7/8" x 1-1/4"(ASA).
- LATCHBOLT: 9/16" Throw. Adjustable front for flat or beveled doors.
- HAND: Non-handed.
- TRIM: Zinc diecast levers/wrought brass rose.
- KEYS: Two change keys per lock.
- Cylinder(s) included
Finishes
Satin Chrome 626/US26D
Installation Challenge Level
Challenging
Recommended for Experienced or Professional Installers.
PDQ Extremely Heavy Duty Cylindrical Lock - XGT116 Entrance/Office
$217.80
US made, this line of grade 1 door locks gives you the best in security, durability, and cost. The XGT is able to withstand over 3,000 in. lbs. of torque resistance on its lever trim.
The XGT116 is an Entrance/Office function lock, where the door is unlocked by a key from the outside when the outer lever is locked by a turn-button on the inside lever. The inside lever is always unlocked.
- Latchbolt operated by lever from either side or key in outside lever
- Outside lever locked by push/turn button on inside
- When outside lever is locked by push button on inside – key from outside,
or rotating inside lever unlocks outside lever - When outside lever is locked by pushing and turning button on the inside,
key from outside or rotating inside lever retracts latch but does not unlock outside lever
We also offer the XGT Series Cylindrical Lock in several other functions - Privacy, Storeroom, Classroom and Passage. Compare Functions.
Features
- ANSI Grade 1 Extremely Heavy Duty cylindrical door lock
- Exceeds 3,000 in lbs. of torque resistance
- High Strength stainless steel investment cast spindle. Heavy gauge steel mounting plates.
- Door Situation: Fits left, right wood/metal swing doors
- Architectural Finish
- Assembled in USA, meeting the requirements of the Buy American Act
- Lifetime Manufacturer's Limited Warranty
Specs
- FOR DOORS: 1-3/4" to 2-1/4" thick. Factory adjusted for 1-3/4"
- DOOR PREP: Fits standard 161 door prep. Through-door thru-bolting.
- BACKSET: 2-3/4" only. Guarded
- FRONT: 2-1/4" x 1-1/8". Beveled 1/8" on 2"
- STRIKE: 4-7/8" x 1-1/4"(ASA).
- LATCHBOLT: 9/16" Throw. Adjustable front for flat or beveled doors.
- HAND: Non-handed.
- TRIM: Zinc diecast levers/wrought brass rose.
- KEYS: Two change keys per lock.
- Cylinder(s) included
Finishes
Satin Chrome 626/US26D
Installation Challenge Level
Challenging
Recommended for Experienced or Professional Installers.
PDQ Extremely Heavy Duty Cylindrical Lock - XGT148 Classroom
$225.00
US made, this line of grade 1 door locks gives you the best in security, durability, and cost. The XGT is able to withstand over 3,000 in. lbs. of torque resistance on its lever trim.
The XGT148 is a Classroom function lock, where the latch bolt is operated by a lever on either side EXCEPT when the outside lever is locked from the outside by a key.
- Latchbolt operated by lever from either side
- Outside lever locked by key from outside
- Outside lever unlocked by key from outside
- Inside lever always operates latch
We also offer the XGT Series Cylindrical Lock in several other functions - Entrance/Office, Privacy, Storeroom and Passage. Compare Functions.
Features
- ANSI Grade 1 Extremely Heavy Duty cylindrical door lock
- Exceeds 3,000 in lbs. of torque resistance
- High Strength stainless steel investment cast spindle. Heavy gauge steel mounting plates.
- Door Situation: Fits left, right wood/metal swing doors
- Architectural Finish
- Assembled in USA, meeting the requirements of the Buy American Act
- Lifetime Manufacturer's Limited Warranty
Specs
- FOR DOORS: 1-3/4" to 2-1/4" thick. Factory adjusted for 1-3/4"
- DOOR PREP: Fits standard 161 door prep. Through-door thru-bolting.
- BACKSET: 2-3/4" only. Guarded
- FRONT: 2-1/4" x 1-1/8". Beveled 1/8" on 2"
- STRIKE: 4-7/8" x 1-1/4"(ASA).
- LATCHBOLT: 9/16" Throw. Adjustable front for flat or beveled doors.
- HAND: Non-handed.
- TRIM: Zinc diecast levers/wrought brass rose.
- KEYS: Two change keys per lock.
- Cylinder(s) included
Finishes
Satin Chrome 626/US26D
Installation Challenge Level
Challenging
Recommended for Experienced or Professional Installers.
PDQ Mortise Lock - MR126 Passage
$230.00
The PDQ MR Series Mortise Lock is a Grade 1 commercial door lock made in the USA. The J Wide Series Trim covers previous fastener holes when replacing other brands of mortise lock.
The MR126 is a Passage function lock, where the latch bolt is operated by the lever from either side at all times. There is no locking function.
- Non keyed
- Latchbolt is operated by lever from either side
We also offer the MR Series Mortise Lock in several other functions - Entrance/Office, Classroom, Privacy, Apartment/Corridor, and Storeroom. Compare Functions.
We carry four lever styles (see photo) and four handing configurations:
- LH: Left Hand - from key side, hinges are on your left and the door swings away from you.
- RH: Right Hand - from key side, hinges are on your right and the door swings away from you.
- LHR: Left Hand Reverse - from key side, hinges are on your left and the door swings toward you.
- RHR: Right Hand Reverse - from key side, hinges are on your right and the door swings toward you.
Features
- Assembled in USA, meeting the requirements of the Buy American Act
- Lifetime Manufacturer's Limited Warranty
- Windstorm Resistant
- 12 ga. Heavy Duty Alloy Steel Case
- Single Cam for All Locking Functions
- Four Compression Springs Eliminate Sagging Levers
- Independent Single Retractor Hub
- Stainless Steel Stop Works, Deadbolt, Latchbolt, Deadlatch and Armor Plate
Specs
- FOR DOORS: 1-3/4"
- BACKSET: 2-3/4"
- CASE: 12-gauge cold rolled steel mechanism, dichromated for corrosion resistance
- ARMOR FRONT: Beveled 1/8" on 2"
- STRIKE: Handed Curved Lip Strike
- LATCHBOLT: 3/4" Throw, Investment Cast Stainless Steel, Anti-friction
- DEADBOLT: 1" Throw, Investment Cast Stainless Steel
- TRIM: Stainless steel escutcheon and levers
Finishes
Satin Stainless Steel 630/US32D
Installation Challenge Level
Challenging
Recommended for Experienced Installers.
INSTRUCTIONS & TEMPLATES
PDQ Mortise Lock - MR176 Privacy
$239.00
The PDQ MR Series Mortise Lock is a Grade 1 commercial door lock made in the USA. The J Wide Series Trim covers previous fastener holes when replacing other brands of mortise lock.
The MR176 is a Privacy function lock featuring thumbturn locking. The lock can be opened from the outside with a coin. The inside push button can be released by turning the inside lever.
- Non keyed
- Latchbolt operated by lever from either side
- Emergency coin turn outside unlocks outside lever
- Thumbturn inside locks/unlocks outside lever
- Closing door unlocks outside lever
- Rotating inside lever unlocks outside lever
We also offer the MR Series Mortise Lock in several other functions - Entrance/Office, Classroom, Apartment/Corridor, Storeroom and Passage. Compare Functions.
We carry four lever styles (see photo) and four handing configurations:
- LH: Left Hand - from key side, hinges are on your left and the door swings away from you.
- RH: Right Hand - from key side, hinges are on your right and the door swings away from you.
- LHR: Left Hand Reverse - from key side, hinges are on your left and the door swings toward you.
- RHR: Right Hand Reverse - from key side, hinges are on your right and the door swings toward you.
Features
- Assembled in USA, meeting the requirements of the Buy American Act
- Lifetime Manufacturer's Limited Warranty
- Windstorm Resistant
- 12 ga. Heavy Duty Alloy Steel Case
- Single Cam for All Locking Functions
- Four Compression Springs Eliminate Sagging Levers
- Independent Single Retractor Hub
- Stainless Steel Stop Works, Deadbolt, Latchbolt, Deadlatch and Armor Plate
Specs
- FOR DOORS: 1-3/4"
- BACKSET: 2-3/4"
- CASE: 12-gauge cold rolled steel mechanism, dichromated for corrosion resistance
- ARMOR FRONT: Beveled 1/8" on 2"
- STRIKE: Handed Curved Lip Strike
- LATCHBOLT: 3/4" Throw, Investment Cast Stainless Steel, Anti-friction
- DEADBOLT: 1" Throw, Investment Cast Stainless Steel
- TRIM: Stainless steel escutcheon and levers
Finishes
Satin Stainless Steel 630/US32D
Installation Challenge Level
Challenging
Recommended for Experienced Installers.
INSTRUCTIONS & TEMPLATES
PDQ Mortise Lock - MR115 Storeroom
$257.00
The PDQ MR Series Mortise Lock is a Grade 1 commercial door lock made in the USA. The J Wide Series Trim covers previous fastener holes when replacing other brands of mortise lock.
The MR115 is a Storeroom function lock, where the latch bolt is operated by a key outside and the lever from the inside. The outside lever is rigid.
- Latchbolt operated by lever from inside
- Key outside retracts latchbolt
- Rigid outside lever
- Auxiliary latch deadlocks latchbolt
We also offer the MR Series Mortise Lock in several other functions - Entrance/Office, Classroom, Privacy, Apartment/Corridor, and Passage. Compare Functions.
We carry four lever styles (see photo) and four handing configurations:
- LH: Left Hand - from key side, hinges are on your left and the door swings away from you.
- RH: Right Hand - from key side, hinges are on your right and the door swings away from you.
- LHR: Left Hand Reverse - from key side, hinges are on your left and the door swings toward you.
- RHR: Right Hand Reverse - from key side, hinges are on your right and the door swings toward you.
Features
- Assembled in USA, meeting the requirements of the Buy American Act
- Lifetime Manufacturer's Limited Warranty
- Windstorm Resistant
- 12 ga. Heavy Duty Alloy Steel Case
- Single Cam for All Locking Functions
- Four Compression Springs Eliminate Sagging Levers
- Independent Single Retractor Hub
- Stainless Steel Stop Works, Deadbolt, Latchbolt, Deadlatch and Armor Plate
Specs
- FOR DOORS: 1-3/4"
- BACKSET: 2-3/4"
- CASE: 12-gauge cold rolled steel mechanism, dichromated for corrosion resistance
- ARMOR FRONT: Beveled 1/8" on 2"
- STRIKE: Handed Curved Lip Strike
- LATCHBOLT: 3/4" Throw, Investment Cast Stainless Steel, Anti-friction
- DEADBOLT: 1" Throw, Investment Cast Stainless Steel
- TRIM: Stainless steel escutcheon and levers
- KEYS: Two (2) per Lock
- KEYWAYS: SCC standard (Schlage C Compatible)
Finishes
Satin Stainless Steel 630/US32D
Installation Challenge Level
Challenging
Recommended for Experienced Installers.
INSTRUCTIONS & TEMPLATES
PDQ Mortise Lock - MR116 Entrance/Office
$257.00
The PDQ MR Series Mortise Lock is a Grade 1 commercial door lock made in the USA. The J Wide Series Trim covers previous fastener holes when replacing other brands of mortise lock.
The MR116 is an Entrance/Office function lock, where the door is unlocked by a key from the outside when the outer lever is locked by a turn-button on the inside lever. The inside lever is always unlocked.
- Latchbolt operated by lever from either side
- Toggle locks/unlocks outside lever
- Key outside retracts latchbolt
- Auxiliary latch deadlocks latchbolt
We also offer the MR Series Mortise Lock in several other functions - Classroom, Privacy, Apartment/Corridor, Storeroom and Passage. Compare Functions.
We carry four lever styles (see photo) and four handing configurations:
- LH: Left Hand - from key side, hinges are on your left and the door swings away from you.
- RH: Right Hand - from key side, hinges are on your right and the door swings away from you.
- LHR: Left Hand Reverse - from key side, hinges are on your left and the door swings toward you.
- RHR: Right Hand Reverse - from key side, hinges are on your right and the door swings toward you.
Features
- Assembled in USA, meeting the requirements of the Buy American Act
- Lifetime Manufacturer's Limited Warranty
- Windstorm Resistant
- 12 ga. Heavy Duty Alloy Steel Case
- Single Cam for All Locking Functions
- Four Compression Springs Eliminate Sagging Levers
- Independent Single Retractor Hub
- Stainless Steel Stop Works, Deadbolt, Latchbolt, Deadlatch and Armor Plate
Specs
- FOR DOORS: 1-3/4"
- BACKSET: 2-3/4"
- CASE: 12-gauge cold rolled steel mechanism, dichromated for corrosion resistance
- ARMOR FRONT: Beveled 1/8" on 2"
- STRIKE: Handed Curved Lip Strike
- LATCHBOLT: 3/4" Throw, Investment Cast Stainless Steel, Anti-friction
- DEADBOLT: 1" Throw, Investment Cast Stainless Steel
- TRIM: Stainless steel escutcheon and levers
- KEYS: Two (2) per Lock
- KEYWAYS: SCC standard (Schlage C Compatible)
Finishes
Satin Stainless Steel 630/US32D
Installation Challenge Level
Challenging
Recommended for Experienced Installers.
INSTRUCTIONS & TEMPLATES
PDQ Mortise Lock - MR148 Classroom
$257.00
The PDQ MR Series Mortise Lock is a Grade 1 commercial door lock made in the USA. The J Wide Series Trim covers previous fastener holes when replacing other brands of mortise lock.
The MR148 is a Classroom function lock, where the latch bolt is operated by a lever on either side EXCEPT when the outside lever is locked from the outside by a key.
- Latchbolt operated by lever from either side
- Key outside retracts latchbolt
- Inside lever always free
- Auxiliary latch deadlocks latchbolt
We also offer the MR Series Mortise Lock in several other functions - Entrance/Office, Privacy, Apartment/Corridor, Storeroom and Passage. Compare Functions.
We carry four lever styles (see photo) and four handing configurations:
- LH: Left Hand - from key side, hinges are on your left and the door swings away from you.
- RH: Right Hand - from key side, hinges are on your right and the door swings away from you.
- LHR: Left Hand Reverse - from key side, hinges are on your left and the door swings toward you.
- RHR: Right Hand Reverse - from key side, hinges are on your right and the door swings toward you.
Features
- Assembled in USA, meeting the requirements of the Buy American Act
- Lifetime Manufacturer's Limited Warranty
- Windstorm Resistant
- 12 ga. Heavy Duty Alloy Steel Case
- Single Cam for All Locking Functions
- Four Compression Springs Eliminate Sagging Levers
- Independent Single Retractor Hub
- Stainless Steel Stop Works, Deadbolt, Latchbolt, Deadlatch and Armor Plate
Specs
- FOR DOORS: 1-3/4"
- BACKSET: 2-3/4"
- CASE: 12-gauge cold rolled steel mechanism, dichromated for corrosion resistance
- ARMOR FRONT: Beveled 1/8" on 2"
- STRIKE: Handed Curved Lip Strike
- LATCHBOLT: 3/4" Throw, Investment Cast Stainless Steel, Anti-friction
- DEADBOLT: 1" Throw, Investment Cast Stainless Steel
- TRIM: Stainless steel escutcheon and levers
- KEYS: Two (2) per Lock
- KEYWAYS: SCC standard (Schlage C Compatible)
Finishes
Satin Stainless Steel 630/US32D
Installation Challenge Level
Challenging
Recommended for Experienced Installers.
INSTRUCTIONS & TEMPLATES
PDQ Mortise Lock - MR162 Apartment/Corridor
$260.00
The PDQ MR Series Mortise Lock is a Grade 1 commercial door lock made in the USA. The J Wide Series Trim covers previous fastener holes when replacing other brands of mortise lock.
The MR162 is an Apartment/Corridor function lock:
- Latchbolt operated by lever from either side
- Toggle locks/unlocks outside lever
- Key outside retracts latchbolt
- Key outside extends/retracts deadbolt
- Thumbturn inside extends/retracts deadbolt
- Inside lever simultaneously retracts latchbolt and deadbolt
- Auxiliary latch deadlocks latchbolt
We also offer the MR Series Mortise Lock in several other functions - Entrance/Office, Classroom, Privacy, Storeroom and Passage. Compare Functions.
We carry four lever styles (see photo) and four handing configurations:
- LH: Left Hand - from key side, hinges are on your left and the door swings away from you.
- RH: Right Hand - from key side, hinges are on your right and the door swings away from you.
- LHR: Left Hand Reverse - from key side, hinges are on your left and the door swings toward you.
- RHR: Right Hand Reverse - from key side, hinges are on your right and the door swings toward you.
Features
- Assembled in USA, meeting the requirements of the Buy American Act
- Lifetime Manufacturer's Limited Warranty
- Windstorm Resistant
- 12 ga. Heavy Duty Alloy Steel Case
- Single Cam for All Locking Functions
- Four Compression Springs Eliminate Sagging Levers
- Independent Single Retractor Hub
- Stainless Steel Stop Works, Deadbolt, Latchbolt, Deadlatch and Armor Plate
Specs
- FOR DOORS: 1-3/4"
- BACKSET: 2-3/4"
- CASE: 12-gauge cold rolled steel mechanism, dichromated for corrosion resistance
- ARMOR FRONT: Beveled 1/8" on 2"
- STRIKE: Handed Curved Lip Strike
- LATCHBOLT: 3/4" Throw, Investment Cast Stainless Steel, Anti-friction
- DEADBOLT: 1" Throw, Investment Cast Stainless Steel
- TRIM: Stainless steel escutcheon and levers
- KEYS: Two (2) per Lock
- KEYWAYS: SCC standard (Schlage C Compatible)
Finishes
Satin Stainless Steel 630/US32D
Installation Challenge Level
Challenging
Recommended for Experienced Installers.
INSTRUCTIONS & TEMPLATES
PDQ Commercial Deadbolt - KV137 Double Cylinder
$55.00
The PDQ KV is Standard Duty Commercial Grade Deadbolt. The PDQ KV Series deadbolt provides tough, effective protection as a security door lock, while still being an affordable deadbolt. This commercial grade deadbolt is easy to install and fits all standard door preparations, and can be installed on wood doors and on hollow metal doors because they have adjustable backset for easy installation.
The PDQ KV137 is a Double Cylinder deadbolt providing the following functionality:
- Lock or unlock by key from both sides
We also offer the KV Series deadbolt in two other functions - Single Sided with Indicator, and Single Cylinder. Compare Functions.
Features
- Adjustable backset deadbolt for easy installation on wood or metal doors
- Architectural Finish
- Assembled in USA, meeting the requirements of the Buy American Act
- Lifetime Manufacturer's Limited Warranty
Specs
- FOR DOORS: 1-1/4" to 1-3/4"
- BACKSET: Adjustable 2-3/8" to 2-3/4"
- FRONT: 2-1/4" x 1", Stainless Steel or Wrought Brass
- STRIKE: 2-3/4" x 1-1/8". Brass or stainless steel.
- DEADBOLT: 1" throw with case-hardened roller pin. Brass.
- HAND: Non-handed.
- TRIM: Stainless steel, wrought brass
- KEYS: Two change keys per lock.
Finishes
Satin Chrome 626/US26D
Dark Oxidized Satin Bronze, Oil Rubbed 626/US10B
Installation Challenge Level
Challenging
Recommended for Experienced or Professional Installers.
INSTRUCTIONS & TEMPLATES
PDQ Commercial Deadbolt - KV116 Single Cylinder
$39.60
The PDQ KV is a Standard Duty Commercial Grade Deadbolt. The PDQ KV Series deadbolt provides tough, effective protection as a security door lock, while still being an affordable deadbolt. This commercial grade deadbolt is easy to install and fits all standard door preparations, and can be installed on wood doors and on hollow metal doors because they have adjustable backset for easy installation.
The PDQ KV116 is a Single Cylinder deadbolt providing the following functionality:
- Lock or unlock by key from outside, by thumb turn from inside
We also offer the KV Series deadbolt in two other functions - Single Sided with Indicator, and Double Cylinder. Compare Functions.
Features
- Adjustable backset deadbolt for easy installation on wood or metal doors
- Architectural Finish
- Assembled in USA, meeting the requirements of the Buy American Act
- Lifetime Manufacturer's Limited Warranty
Specs
- FOR DOORS: 1-1/4" to 1-3/4"
- BACKSET: Adjustable 2-3/8" to 2-3/4"
- FRONT: 2-1/4" x 1", Stainless Steel or Wrought Brass
- STRIKE: 2-3/4" x 1-1/8". Brass or stainless steel.
- DEADBOLT: 1" throw with case-hardened roller pin. Brass.
- HAND: Non-handed.
- TRIM: Stainless steel, wrought brass
- KEYS: Two change keys per lock.
Finishes
Satin Chrome 626/US26D
Dark Oxidized Satin Bronze, Oil Rubbed 626/US10B
Installation Challenge Level
Challenging
Recommended for Experienced or Professional Installers.
INSTRUCTIONS & TEMPLATES
PDQ Commercial Deadbolt - KV125 IND Single Sided with Indicator
$55.00
The PDQ KV is Standard Duty Commercial Grade Deadbolt. The PDQ KV Series deadbolt provides tough, effective protection as a security door lock, while still being an affordable deadbolt. This commercial grade deadbolt is easy to install and fits all standard door preparations, and can be installed on wood doors and on hollow metal doors because they have adjustable backset for easy installation.
The PDQ KV125 IND is a Single Sided with Indicator deadbolt providing the following functionality:
- No key outside
- Indicator outside
- ADA compliant thumbturn inside extends/retracts deadbolt
- Emergency key outside retracts deadbolt
We also offer the KV Series deadbolt in two other functions - Double Cylinder and Single Cylinder. Compare Functions.
Features
- Americans with Disabilities Act (ADA) Compliant
- Adjustable backset deadbolt for easy installation on wood or metal doors
- Architectural Finish
- Assembled in USA, meeting the requirements of the Buy American Act
- Lifetime Manufacturer's Limited Warranty
Specs
- FOR DOORS: 1-1/4" to 1-3/4"
- BACKSET: Adjustable 2-3/8" to 2-3/4"
- FRONT: 2-1/4" x 1", Stainless Steel or Wrought Brass
- STRIKE: 2-3/4" x 1-1/8". Brass or stainless steel.
- DEADBOLT: 1" throw with case-hardened roller pin. Brass.
- HAND: Non-handed.
- TRIM: Stainless steel, wrought brass
- KEYS: Two change keys per lock.
Finishes
Satin Chrome 626/US26D
Dark Oxidized Satin Bronze, Oil Rubbed 626/US10B
Installation Challenge Level
Challenging
Recommended for Experienced or Professional Installers.
INSTRUCTIONS & TEMPLATES
Simplex Mechanical Pushbutton Lock 1000 Series - Knob
$550.00
The Simplex 1000 Series provides exterior access by combination, while allowing free egress. This mechanical lock, with knob option, eliminates the material and labor expense of battery replacements, has a single access-code and is programmed via the keypad without removing the lock from the door.
Features
- Locking Device: Cylindrical latch with 3-hour UL/ULC fire rating on "A" labeled doors
- Number of Codes: Single access code—one easy-to-manage code for all users
- Programming: Lock is easily programmed via keypad without removing lock from the door
Specs
- Construction: Heavy-duty cylindrical lock housing with cast front housing; unified trim plate; cast knobs
- Numeric Keypad: Vandal resistant, solid metal pushbuttons
- Handing: Factory-handed for left-hand doors; easily field reversible
- Backset: 2¾" (70 mm), 2⅜" (60 mm)
- Latch: ½" (13 mm) throw latch, ¾"
- Minimum Stile Recommended: 5" (127 mm)
- Strike: Standard strike plate; ASA strike plate
- Schlage core
- Door Preparation: Easily installs on wood or metal doors. ASA 161 door preparation with additional through bore holes required.
- Door Thickness: 1⅜" (35 mm) to 2¼" (57 mm)—Pre-assembled to accommodate 1⅝" (41 mm) to 2" (51 mm)
- Durability: D.O.D. Compliant 5220.22M for supplemental access control; weather resistant
- Fire Rating: 3-hour UL/ULC fire rating for "A" labeled doors
- Warranty: 3-year warranty
Finishes
Satin Chrome 626/US26D
Installation Challenge Level
Challenging
Recommended for Experienced Installers, but not rocket science.
Instructions & Templates
Simplex Mechanical Pushbutton Lock L1000 Series - Lever
$462.00
The Simplex L1000 Series provides exterior access by combination, while allowing free egress. This mechanical lock, with lever option, eliminates the material and labor expense of battery replacements, has a single access-code and is programmed via the keypad without removing the lock from the door.
Features
- Locking Device: Cylindrical latch with 3-hour UL/ULC fire rating on "A" labeled doors
- Number of Codes: Single access code—one easy-to-manage code for all users
- Programming: Lock is easily programmed via keypad without removing lock from the door
- Handing: Factory-handed , handing required when ordering.
Specs
- Construction: Heavy-duty cylindrical lock housing with cast front housing; unified trim plate; cast knobs
- Numeric Keypad: Vandal resistant, solid metal pushbuttons
- Handing: Factory-handed for left-hand doors; not field reversible.
- Backset: 2¾" (70 mm), 2⅜" (60 mm)
- Latch: ½" (13 mm) throw latch, ¾"
- Minimum Stile Recommended: 5" (127 mm)
- Strike: Standard strike plate; ASA strike plate
- Key Override: Schlage core
- Door Preparation: Easily installs on wood or metal doors. ASA 161 door preparation with additional through bore holes required.
- Door Thickness: 1⅜" (35 mm) to 2¼" (57 mm)—Pre-assembled to accommodate 1⅝" (41 mm) to 2" (51 mm)
- Durability: D.O.D. Compliant 5220.22M for supplemental access control; weather resistant
- Fire Rating: 3-hour UL/ULC fire rating for "A" labeled doors
- Warranty: 3-year warranty
Finishes
Satin Chrome 626/US26D
Installation Challenge Level
Challenging
Recommended for Experienced Installers, but not rocket science.
Instructions & Templates
Alarm Lock DL2700 Access Control Digital Lock
$392.70
The DL2700 electronic digital lock leverset is programmable through the keypad for 100 user entry codes for secure keyless entry. Cylindrical lock mechanism has a fixed 6-pin key cylinder with SC1 keyway for key override. For installation on exterior and interior doors, and rated for temperatures from -31 to +151 degrees F (-35 to +66 degrees C). Lever handle is reversible for right- or left-hand operation. Stainless steel trim with satin chrome finish resists corrosion.
Features
- In an hour, add a dependable wireless access control keyless door lock, one door at a time—easily retrofit standard knobsets
- Support 100 PIN codes (3-5 or 6 digits)
- Multi-level user codes & one-time service codes. Free passage, group- or total lock-out modes, too on Trilogy security locks
- All keyless entry door locks are fingertip programmable at vandalproof all-metal keypad
- Long-life battery operation, low battery alert
- Key override on all Trilogy electronic locks, standard core (supplied) or interchangeable core prep
- Non-handed cylindrical models
- Programmable relay functions
- Durable BHMA Grade 1 Lockset
- Weatherproof models -31˚ to +151˚F (-35˚ to +66˚C). Rugged electronic door lock
Specs
- More codes: up to 100 3-5 digit codes: 1 master, 10 managers, 90 basic users, 3 one-time service codes
- 5AA battery operated; 175,000 cycles, typ.
- For outdoors, specify WP weatherproof models -31˚ to +151˚F (-35˚ to +66˚C)
Finishes
Satin Chrome 626/US26D
Installation Challenge Level
Challenging
Recommended for Experienced Installers, but not rocket science.
Instructions & Templates
Amarlite Lock Replacement
$75.00
This is the only exact replacement for the original Amarlite Telescopic Bolt Lock. Manufactured to the exact specifications of the original Amarlite Lock, it allows for rapid installation and eliminates all need for additional difficult and time consuming alterations to the door. Cylinder holes are threaded for the original Amarlite cylinders as well as any standard size mortise cylinders.
*Does not include actual cylinder.
PDQ Extremely Heavy Duty Cylindrical Lock - XGT135 Intruder Classroom
$255.00
Extremely Heavy Duty Cylindrical Lock - XGT135 Intruder Classroom
US made, this line of grade 1 door locks gives you the best in security, durability, and cost. The XGT is able to withstand over 3,000 in. lbs. of torque resistance on its lever trim.
The XGT135 is a Classroom function lock, where the latch bolt is operated by a lever on either side EXCEPT when the outside lever is locked from the outside by a key.
- Latchbolt operated by lever from either side
- Outside lever locked by key from outside
- Outside lever unlocked by key from outside
- Inside lever always operates latch
We also offer the XGT Series Cylindrical Lock in several other functions - Entrance/Office, Privacy, Storeroom and Passage. Compare Functions.
Features
- ANSI Grade 1 Extremely Heavy Duty cylindrical door lock
- Exceeds 3,000 in lbs. of torque resistance
- High Strength stainless steel investment cast spindle. Heavy gauge steel mounting plates.
- Door Situation: Fits left, right wood/metal swing doors
- Architectural Finish
- Assembled in USA, meeting the requirements of the Buy American Act
- Lifetime Manufacturer's Limited Warranty
Specs
- FOR DOORS: 1-3/4" to 2-1/4" thick. Factory adjusted for 1-3/4"
- DOOR PREP: Fits standard 161 door prep. Through-door thru-bolting.
- BACKSET: 2-3/4" only. Guarded
- FRONT: 2-1/4" x 1-1/8". Beveled 1/8" on 2"
- STRIKE: 4-7/8" x 1-1/4"(ASA).
- LATCHBOLT: 9/16" Throw. Adjustable front for flat or beveled doors.
- HAND: Non-handed.
- TRIM: Zinc diecast levers/wrought brass rose.
- KEYS: Two change keys per lock.
- Cylinder(s) included
Finishes
Satin Chrome 626/US26D
Installation Challenge Level
Challenging
Recommended for Experienced or Professional Installers.
Cal-Royal CR3000 Series
$396.37
Grade 1 Heavy Duty Digital Keypad Door Lock
For Offices, Schools, Hospitals, Apartments, Hotel / Motel, Residential, Commercial, and Public Buildings
- Meets or exceeds requirements of BHMA / ANSI A156.2 Series 4000, GRADE 1
- Easy Installation & Programming
- Long-Life Battery Operation
- 2 Remote Switch Terminals
- Interchangeable Core
- Master Code
- 10 Manager Codes
- 1 Sub-Master Code
- 90 User Codes
- 5 Service Codes
- Passage Mode
- Weather Resistant
- Buzzer & Led Indicators
- Anti-Tamper Lockout
- Clutch Technology
- Non-Handed, Reversible
- Enable & Disable Users Mode
- Tactile Metal Keypad
- User Friendly
- Master Code – performs all programming functions.
- Sub-Master Code – performs all programming functions except delete or change Master Code.
- Manager Codes – CR3000 can accommodate 10 Managers each having different codes and under each Manager has 9 Users (1 Manager + 9 Users = 1 Bank). Managers are capable of programming / adding and deleting User codes under his Bank. Managers are also capable of accessing the next higher bank until another Manager Code appears.
- Service Codes (5) – are one-time codes only. It cannot be used again. Once a Service Code is entered, the unit will unlock but will automatically delete the code.
- Passage Mode – once enabled, the unit is unlocked continuously until “Disable Passage Mode” is initiated.
- Tones and LED Indicators – can be programmed for different settings. Making sure that every key pressed is confirmed by an accompanying LED and/or tone.
- Next Free Code Location Finder – no need of guessing what free location is available in entering a new code. CR3000 can pinpoint and tell you where the next available location is.
- Code Locator Function – CR3000 can tell you the exact location of a certain code. Making it easy to determine what manager a user code is under.
- Keypad Anti-Tamper Lockout – if an invalid code is entered 3 times in succession, the unit will turn off for 30 seconds to prevent tampering.
- Remote Switch Terminal / Release – CR3000 provides 2 Remote Switch Terminal. Either can be used for an emergency push button switch, or connected to alarm systems such as fire alarms.
- Weather Resistant – CR3000 are manufactured making sure that internal electronic parts are protected from moisture, dust, water, and corrosion. All models are weather-resistant for temperature ranges of +158°F to -22°F (+70°C to -30°C).
- Clutch Technology – the outside lever of the CR3000 is a free-wheeling lever. If no valid code is entered, the lever will just turn freely without moving any parts inside, thus preventing breaking or tampering.
- Non-Handed – CR3000 can be installed for both left and right door opening.
- APPLICATIONS For offices, schools, hospitals, apartments, hotel/motel, residential, commercial, and public buildings.
- DOOR RANGES 1 ⅜” to 2” thickness.
- BACKSET 2 ¾” Standard, 2 ⅜”, 3 ¾”, 5” and 2 ¾” anti-friction latch with ¾” throw for pair of fire doors optional.
- LATCH FACEPLATE Standard 2 ¼” x 1 ⅛” for 2 ¾” backset. Optional 2 ¼” x 1 ⅛” for 2 ⅜” backset.
- STRIKES ASA strike standard, “T” and full lip strike available on request.
- ANSI STANDARDS Meets or exceeds BHMA/ANSI A156.2 Series 4000 Grade 1 requirements.
- POWER SUPPLY 4 AA Batteries (comes standard in packing)
- CLUTCH Clutch technology allows turning of lever without retracting the latch, thus prolonging the life of the lock by reducing stress on the spindle and other parts.
- CYLINDER & KEYWAYS 6 pin solid brass “C” keyway standard. Schlage E, Schlage C-K, Russwin D1-2-3-4, Corbin 59/60, Corbin-Russwin L4, Sargent LA-LB-LC, Falcon / Weiser E, Arrow A, Yale 8, Yale GA and Kwikset. Can also accept Medeco, Assa, Kaba and Cal-Royal (HSK) High-Security Cylinders.
- INTERCHANGEABLE CORE (IC) Interchangeable Core locks will accept compatible 6 or 7 pin cores with BEST, FALCON, and ARROW. Prefix “IC” before part number.
- WEATHER RESISTANT All models are weather-resistant for temperature ranges of +158○F to -22○F (+70○C to -30○C).
- KEYPAD 12 programmable buttons for multi-level access functions including group or individual user codes, master and management codes, passage, and emergency or service codes.
-
(IC) Indicates function available with BEST, FALCON & ARROW Interchangeable Core.
Installation Challenge Level
Challenging
Recommended for Experienced Installers, but not rocket science.
Cal-Royal Pioneer SL/CSL Series - SL00-Office / Entry Lock
$70.00
Grade 2 Locksets
For Offices, Schools, Hospitals, Apartments, Hotel / Motel, Residential, Commercial and Public Buildings.
- BHMA Certified Lifetime Warranty, GRADE 2
- Conforms with ANSI A 156.2 Series 4000, Heavy Duty, Barrier Free
- UL listed 3-hour rating, conforms to standards UL10C and UBC7-2-1997
- Solid brass 6 pin “C” keyway cylinder, optional other keyways
- Optional Interchangeable Core
- Optional Clutch System (CSL Series), free turning handle to deter breaking of the handle
- Optional thru bolt installation
- Individual spring on each side to prevent lever sag, maintain reliability and reduce maintenance
- Optional Tactile and Lead Lining
- Hurricane Approved Hardware. Florida Building Code FL13922
- Meets the Buy American Act
Features
- APPLICATIONS For offices, schools, hospitals, apartments, hotel / motel, residential, commercial and public buildings.
- DOOR RANGES 1 ⅜” to 1 ¾” thickness doors.
- BACKSET 2 ¾” Standard, 2 ⅜”, 3 ¾” and 5” optional.
- LATCH BOLT ½” Throw solid brass, reversible for RH or LH applications. UL Listed.
- LATCH FACEPLATE 2 ¼” x 1 ⅛”, adjustable for flat or beveled doors ⅛” in 2”, for 2 ¾” backset. Optional 2 ¼” x 1” for 2 ⅜” backset.
- ANSI STANDARDS Meets or exceeds requirements of BHMA / ANSI A156.2 Series 4000, Grade 2 (FF-H 106C), 400,000 cycles.
- EXPOSED TRIM Wrought brass, bronze or stainless steel, levers are Zinc casting, plated to match trim finish.
- KEYING 6-pin “C” keyway cylinder, 2 keys per lock. Keying as per individual job requirement.
- CYLINDER & KEYWAYS 6 pin solid brass “C” keyway standard. Schlage E, Schlage C-K, Russwin D1-2-3-4, Corbin 59 / 60, Corbin-Russwin L4, Sargent LA-LB-LC, Falcon / Weiser E, Arrow A, Yale 8, Yale GA and Kwikset. Can also accept Medeco, Assa, Kaba and Cal-Royal (HSK) High Security Cylinders.
- CLUTCH Clutch available on all keyed locks and privacy functions. Prefix“C” before part number.
- INTERCHANGEABLE CORE Interchangeable Core locks will accept compatible 6 or 7 pin cores with BEST, FALCON and ARROW. Prefix “IC” before part number. Available combinated or uncombinated. Temporary construction cores available. Factory keying with control key and master key available.
- STRIKES ASA strike standard, “T” and full lip strike available on request.
- TACTILE & LEAD LINING available upon request.
Finishes
-
Satin Chrome -
Polished Brass -
Satin Stainless Steel
Templates
Installation Instructions
Catalog Page
Cal-Royal Pioneer SL/CSL Series - RL00 Office / Entry Lock
$70.00
Grade 2 Locksets
For Offices, Schools, Hospitals, Apartments, Hotel / Motel, Residential, Commercial and Public Buildings.
- BHMA Certified Lifetime Warranty, GRADE 2
- Conforms with ANSI A 156.2 Series 4000, Heavy Duty, Barrier Free
- UL listed 3-hour rating, conforms to standards UL10C and UBC7-2-1997
- Solid brass 6 pin “C” keyway cylinder, optional other keyways
- Optional Interchangeable Core
- Optional Clutch System (CSL Series), free turning handle to deter breaking of the handle
- Optional thru bolt installation
- Individual spring on each side to prevent lever sag, maintain reliability and reduce maintenance
- Optional Tactile and Lead Lining
- Hurricane Approved Hardware. Florida Building Code FL13922
- Meets the Buy American Act
Features
- APPLICATIONS For offices, schools, hospitals, apartments, hotel / motel, residential, commercial and public buildings.
- DOOR RANGES 1 ⅜” to 1 ¾” thickness doors.
- BACKSET 2 ¾” Standard, 2 ⅜”, 3 ¾” and 5” optional.
- LATCH BOLT ½” Throw solid brass, reversible for RH or LH applications. UL Listed.
- LATCH FACEPLATE 2 ¼” x 1 ⅛”, adjustable for flat or beveled doors ⅛” in 2”, for 2 ¾” backset. Optional 2 ¼” x 1” for 2 ⅜” backset.
- ANSI STANDARDS Meets or exceeds requirements of BHMA / ANSI A156.2 Series 4000, Grade 2 (FF-H 106C), 400,000 cycles.
- EXPOSED TRIM Wrought brass, bronze or stainless steel, levers are Zinc casting, plated to match trim finish.
- KEYING 6-pin “C” keyway cylinder, 2 keys per lock. Keying as per individual job requirement.
- CYLINDER & KEYWAYS 6 pin solid brass “C” keyway standard. Schlage E, Schlage C-K, Russwin D1-2-3-4, Corbin 59 / 60, Corbin-Russwin L4, Sargent LA-LB-LC, Falcon / Weiser E, Arrow A, Yale 8, Yale GA and Kwikset. Can also accept Medeco, Assa, Kaba and Cal-Royal (HSK) High Security Cylinders.
- CLUTCH Clutch available on all keyed locks and privacy functions. Prefix“C” before part number.
- INTERCHANGEABLE CORE Interchangeable Core locks will accept compatible 6 or 7 pin cores with BEST, FALCON and ARROW. Prefix “IC” before part number. Available combinated or uncombinated. Temporary construction cores available. Factory keying with control key and master key available.
- STRIKES ASA strike standard, “T” and full lip strike available on request.
- TACTILE & LEAD LINING available upon request.
Finishes
-
Satin Chrome
-
Polished Brass
-
Satin Stainless Steel
Templates
Installation Instructions
Catalog Page
INSTALLATION CHALLENGE LEVEL
Challenging
Recommended for Experienced or Professional Installers.
Cal-Royal Pioneer SL/CSL Series - AG00-Office/Entry Lock
$70.00
Grade 2 Locksets
For Offices, Schools, Hospitals, Apartments, Hotel / Motel, Residential, Commercial and Public Buildings.
- BHMA Certified Lifetime Warranty, GRADE 2
- Conforms with ANSI A 156.2 Series 4000, Heavy Duty, Barrier Free
- UL listed 3-hour rating, conforms to standards UL10C and UBC7-2-1997
- Solid brass 6 pin “C” keyway cylinder, optional other keyways
- Optional Interchangeable Core
- Optional Clutch System (CSL Series), free turning handle to deter breaking of the handle
- Optional thru bolt installation
- Individual spring on each side to prevent lever sag, maintain reliability and reduce maintenance
- Optional Tactile and Lead Lining
- Hurricane Approved Hardware. Florida Building Code FL13922
- Meets the Buy American Act
Features
- APPLICATIONS For offices, schools, hospitals, apartments, hotel / motel, residential, commercial and public buildings.
- DOOR RANGES 1 ⅜” to 1 ¾” thickness doors.
- BACKSET 2 ¾” Standard, 2 ⅜”, 3 ¾” and 5” optional.
- LATCH BOLT ½” Throw solid brass, reversible for RH or LH applications. UL Listed.
- LATCH FACEPLATE 2 ¼” x 1 ⅛”, adjustable for flat or beveled doors ⅛” in 2”, for 2 ¾” backset. Optional 2 ¼” x 1” for 2 ⅜” backset.
- ANSI STANDARDS Meets or exceeds requirements of BHMA / ANSI A156.2 Series 4000, Grade 2 (FF-H 106C), 400,000 cycles.
- EXPOSED TRIM Wrought brass, bronze or stainless steel, levers are Zinc casting, plated to match trim finish.
- KEYING 6-pin “C” keyway cylinder, 2 keys per lock. Keying as per individual job requirement.
- CYLINDER & KEYWAYS 6 pin solid brass “C” keyway standard. Schlage E, Schlage C-K, Russwin D1-2-3-4, Corbin 59 / 60, Corbin-Russwin L4, Sargent LA-LB-LC, Falcon / Weiser E, Arrow A, Yale 8, Yale GA and Kwikset. Can also accept Medeco, Assa, Kaba and Cal-Royal (HSK) High Security Cylinders.
- CLUTCH Clutch available on all keyed locks and privacy functions. Prefix“C” before part number.
- INTERCHANGEABLE CORE Interchangeable Core locks will accept compatible 6 or 7 pin cores with BEST, FALCON and ARROW. Prefix “IC” before part number. Available combinated or uncombinated. Temporary construction cores available. Factory keying with control key and master key available.
- STRIKES ASA strike standard, “T” and full lip strike available on request.
- TACTILE & LEAD LINING available upon request.
Finishes
-
Satin Chrome
-
Polished Brass
-
Satin Stainless Steel
Templates
Installation Instructions
Catalog Page
INSTALLATION CHALLENGE LEVEL
Challenging
Recommended for Experienced or Professional Installers.
Cal-Royal Explorer XP/XPRL Series - XPRL00
$85.00
Grade 2 Locksets
For Offices, Schools, Hospitals, Apartments, Hotel / Motel, Residential, Commercial and Public Buildings.
- BHMA Certified Lifetime Warranty, GRADE 2
- Conforms with ANSI A 156.2 Series 4000, Heavy Duty, Barrier Free
- UL listed 3-hour rating, conforms to standards UL10C and UBC7-2-1997
- Solid brass 6 pin “C” keyway cylinder, optional other keyways
- Optional Interchangeable Core
- Non-Clutch Mechanism
- Optional thru-bolted installation
- Individual spring on each side to prevent lever sag, maintain reliability and reduce maintenance
- Optional Tactile and Lead Lining
- Meets the Buy American Act
Features
- APPLICATIONS For offices, schools, hospitals, apartments, hotel / motel, residential, commercial and public buildings.
- DOOR RANGES 1 ⅜” to 2” thickness doors.
- BACKSET 2 ¾” Standard, 2 ⅜”, 3 ¾” and 5” optional.
- LATCH BOLT ½” Throw solid brass, reversible for RH or LH applications. UL Listed.
- LATCH FACEPLATE 2 ¼” x 1”, square corner packed with ⅛” plastic filler for 1 ⅛” width.
- ANSI STANDARDS Meets or exceeds requirements of BHMA/ANSI A156.2 Series 4000, Grade 2 (FF-H 106C), 400,000 cycles.
- EXPOSED TRIM Wrought brass, bronze or stainless steel, levers are Zinc casting, plated to match trim finish.
- KEYING 6-pin “C” keyway cylinder, 2 keys per lock. Keying as per individual job requirement.
- CYLINDER & KEYWAYS 6 pin solid brass “C” keyway standard. Schlage E, Schlage C-K, Russwin D1-2-3-4, Corbin 59 / 60, Corbin-Russwin L4, Sargent LA-LB-LC, Falcon / Weiser E, Arrow A, Yale 8, Yale GA and Kwikset. Can also accept Medeco, Assa, Kaba and Cal-Royal (HSK) High Security Cylinders.
- INTERCHANGEABLE CORE (IC) Interchangeable Core locks will accept compatible 6 or 7 pin cores with BEST, FALCON and ARROW. Prefix “IC” before part number. Available combinated or uncombinated. Temporary construction cores available. Factory keying with control key and master key available.
- STRIKES ASA strike standard, “T” and full lip strike available on request.
- TACTILE & LEAD LINING available upon request.
Finishes
-
US26D Satin Chrome Plated
-
US10B Dark Bronze
Templates
Installation Instructions
Part Numbers
Catalog Page
Challenging
Recommended for Experienced or Professional Installers
Cal-Royal Explorer XP/XPRL Series - XP-T360-05
$128.00
Grade 2 Locksets
For Offices, Schools, Hospitals, Apartments, Hotel / Motel, Residential, Commercial and Public Buildings.
- BHMA Certified Lifetime Warranty, GRADE 2
- Conforms with ANSI A 156.2 Series 4000, Heavy Duty, Barrier Free
- UL listed 3-hour rating, conforms to standards UL10C and UBC7-2-1997
- Solid brass 6 pin “C” keyway cylinder, optional other keyways
- Optional Interchangeable Core
- Non-Clutch Mechanism
- Optional thru-bolted installation
- Individual spring on each side to prevent lever sag, maintain reliability and reduce maintenance
- Optional Tactile and Lead Lining
- Meets the Buy American Act
Features
- APPLICATIONS For offices, schools, hospitals, apartments, hotel / motel, residential, commercial and public buildings.
- DOOR RANGES 1 ⅜” to 2” thickness doors.
- BACKSET 2 ¾” Standard, 2 ⅜”, 3 ¾” and 5” optional.
- LATCH BOLT ½” Throw solid brass, reversible for RH or LH applications. UL Listed.
- LATCH FACEPLATE 2 ¼” x 1”, square corner packed with ⅛” plastic filler for 1 ⅛” width.
- ANSI STANDARDS Meets or exceeds requirements of BHMA/ANSI A156.2 Series 4000, Grade 2 (FF-H 106C), 400,000 cycles.
- EXPOSED TRIM Wrought brass, bronze or stainless steel, levers are Zinc casting, plated to match trim finish.
- KEYING 6-pin “C” keyway cylinder, 2 keys per lock. Keying as per individual job requirement.
- CYLINDER & KEYWAYS 6 pin solid brass “C” keyway standard. Schlage E, Schlage C-K, Russwin D1-2-3-4, Corbin 59 / 60, Corbin-Russwin L4, Sargent LA-LB-LC, Falcon / Weiser E, Arrow A, Yale 8, Yale GA and Kwikset. Can also accept Medeco, Assa, Kaba and Cal-Royal (HSK) High Security Cylinders.
- INTERCHANGEABLE CORE (IC) Interchangeable Core locks will accept compatible 6 or 7 pin cores with BEST, FALCON and ARROW. Prefix “IC” before part number. Available combinated or uncombinated. Temporary construction cores available. Factory keying with control key and master key available.
- STRIKES ASA strike standard, “T” and full lip strike available on request.
- TACTILE & LEAD LINING available upon request.
Finishes
-
US26D Satin Chrome Plated
-
US10B Dark Bronze
Templates
Installation Instructions
Part Numbers
Catalog Page
INSTALLATION CHALLENGE LEVEL
Challenging
Recommended for Experienced or Professional Installers.
Cal-Royal CR6000 Digital Lock with RFID Proximity Card Capability
$520.00
Grade 1 Heavy Duty Digital Touch Screen Door Lock
For Offices, Schools, Hospitals, Apartments, Condo Units, Hotel/Motel, Residential, Commercial, and Public Buildings
- Meets or exceeds requirements of BHMA/ANSI A156.2 Series 4000, GRADE 1
- Easy Installation & Programming
- Master Code
- 3 Manager Codes
- 1,000 User Codes (Combined RFID & User Pin Code)
- 3 Service Codes
- Passage Mode
- 4-6 Digit Code Combination
- Weather Resistant
- 9V Battery
- Anti-Tamper Lockout
- Lock-Out Mode
- Clutch Technology
- Non-Handed Reversible
- Touch Screen
- Wake-Up Button
- Proximity Cart (13.56 MHz)
- RFID Keyfob
- User Friendly
- Master PIN Code - Use for programming the lock and entering Manager and User PIN codes. Can also be used to open the lock and reset to factory settings.
- Manager PIN Code - Use to open the door with lockout mode. Also functions like a User PIN code. This feature can also program 3 one-time user codes.
- User PIN Code - This feature only opens the lock by entering the code on the touchpad. It won’t be able to program or change settings. This lock can accommodate up to 1000, 3 to 6 digits combined RFID and User PIN codes.
- One-Time User PIN Code - Can only be used once. This lock can store up to 3 one-time User PIN code simultaneously.
- Passage Mode - Enabling passage mode allows continuous entry for non-restricted traffic. Passage mode can either be enabled or disabled by the Master Pin code. When in passage mode, the unlocked padlock icon will appear on the screen.
- Beep & LED Indicators - These indicators can either be programmed for different settings. This feature is useful in making sure that every keypress was successfully entered.
- Lock-Out Mode - This feature can either be enabled by the Master or Manager PIN Codes. When enabled, it restricts all User PIN codes access except Master and Manager PIN codes.
-
SMART Card
- Compatible with existing MIFARE infrastructures
- Operates at 13.56 MHz in accordance with ISO14443A
- Inductive distance up to 1 3/16”
- Touch Screen Anti-Tamper Lock Out - This function will auto shut off the lock if an invalid code is entered 5 times in succession to prevent tampering.
- Weather Resistant - CR6000 are manufactured making sure that internal electronic parts are protected from moisture, dust, water, and corrosion. All models are weather-resistant for temperature ranges of 30○F ~ 150○F (-35○C ~ +66○C).
- Wake-Up Button - Pressing this button activates the number pad. Enter the PIN code when while the number pad is illuminated. This button is also used to quit programming mode.
(IC) Indicates function available with BEST, FALCON & ARROW Interchangeable Core.
- APPLICATIONS For offices, schools, hospitals, apartments, condo units, hotel/motel, residential, commercial, and public buildings.
- DOOR RANGES 1 ⅜” to 2”.
- BACKSET 2 ¾” standard or 2 ⅜” optional backset.
- LATCH FACEPLATE Standard 1 ⅛” x 2 ¼” for 2 ¾” backset. Optional 1” x 2 ¼” for 2 ⅜” backset.
- STRIKES ASA Strike standard, T and full lip strike available on request.
- ANSI STANDARDS Certified ANSI / BHMA A156.2 Series 4000 Grade 1 requirements.
- CLUTCH Clutch technology allows turning of lever without retracting the latch, thus prolonging the life of the lock by reducing stress on the spindle and other parts.
- PROXIMITY CARD (STANDARD) Compatible with existing MIFARE infrastructures. Operates at 13.56 MHz in accordance with ISO 14443A. Inductive distance up to 1 3/16”.
- CYLINDER 6-pin solid brass “Schlage C” keyway standard with two brass keys per lock.
- RFID KEYFOB (OPTIONAL) Operates at 13.56 MHz in accordance with ISO 14443A. Inductive distance up to 1 3/16”.
- INTERCHANGEABLE CORE (IC) Interchangeable Core locks will accept compatible 6 or 7 pin cores with BEST and FALCON. Prefix “IC” before part number.
- WEATHER RESISTANT All models are weather-resistant for temperature ranges of -30○F ~ 150○F (-35○C ~ 66○C).
- TOUCH SCREEN Responds to human touch enabling convenient entrance or access to the programming menu. After the operation has been completed, the lock reverts to sleep mode.
https://www.cal-royal.com/files/CR6000_Template.pdf
https://www.cal-royal.com/files/Installation-Programming-guide-for-CR6000-rev2.0.pdf
https://www.cal-royal.com/files/CR6000_Template__Quick_Installation__Program_Guide.pdf
https://www.cal-royal.com/component/opencart/p-237-cr6000-series
Challenging
Recommended for Experienced Installers
Cal-Royal CR6100 SERIES Digital Lock /RFID Card/KeyFob
$475.00
Digital Touch Screen Door Lock with Clutch Technology
PACKAGING: Includes 2 ¾” x 1 ⅛” backset, 6 Pin “C” Keyway, 2 RFID Cards, 4 Batteries, and ASA Strike.
Optional Interchangeable Core for Best, Falcon and Arrow
-
Master Code
-
500 User Codes
-
500 RFID Card/KeyFob per Lock
-
2 on Time User Codes
-
4-6 Digit Code Combination
-
Passage Mode
-
Weather Resistant
-
9V Battery Emergency Port
-
Anti-Tamper Lockout
-
Lock-Out Mode
-
Clutch Technology
-
Non-Handed Reversible
-
Proximity Cart (13.56 MHz)
-
RFID Keyfob (Optional)
-
Mobile App for Android & Apple
-
Bluetooth Reciever (Optional)
-
Touch Screen to Wake Up Lock
FEATURES
- Access Log (Audit Trail) - The ExperienSmart app features a 24/7 activity log, so you can keep track of who accessed the lock. A timestamped access log can be saved as an excel file via email.
- Anti-Tamper Lock-Out - The lock will shut down for 60 seconds and not allow operation, If invalid code is entered 5 times in succession to prevent tampering.
- Beep & LED Indicators - These Indicators can either be programmed for different settings. This Features is useful in making sure that every keypress was successfully entered.
- Bluetooth Receiver (Item # CR6000-BLE) - Optional Device used for managing locks via the ExperienSmart app, 8m to 10m detection range.
- Lock-Out Mode - This feature is enabled by the Master PIN Code. When enabled, It Retricts all User PIN codes and RIFD CARD / KEYFOB access except Master PIN code. The padlock icon will appear on the screen when the unit is in lock-out mode.
- Low Battery Warning - The low battery icon on the screen will blink when battery power is low
- Master PIN Code - Use for programming the lock and entering Manager and User PIN codes. Can also be used to open the lock and reset to factory settings.
- NFC (Near Field Communication) Interface - NFC compatible for android phones.
- One-Time User PIN Code - Can only be used once. This lock can store up to 2 one-time User PIN code simultaneously.
- Passage Mode - Enabling passage mode allows continuous entry for non-restricted traffic. Passage mode can either be enabled or disabled by the Master Pin code. When in passage mode, the unlocked padlock icon will appear on the screen.
- Re-Lock Time - When the code is successfully entered and the device unlocks, it will automatically relock after 5 seconds by default. Through feature settings, the re-lock time may be changed from 1 to 10 seconds..
-
RFID Card (Standard); RFID keyfob (optional)
- Compatible with existing MIFARE infrastructures
- Operates at 13.56 MHz in accordance with ISO14443A
- Inductive distance up to 1 3/16”
- Touch Screen (Lock Activation) - Touch the screen to activate lock. Enter the PIN code when while the number pad is illuminated. Also same as using the RFID card/keyfob.
- User PIN Code - This Feature only opens the lock by entering the code on the touch pad. It won't be able to program or change settings. This lock can accommodate up to 500 RFID Card/Keyfob and 500 User PIN codes each, 4 to 6 digit combination.
- Weather Resistant - CR6000 are manufactured making sure that internal electronic parts are protected from moisture, dust, water, and corrosion. All models are weather-resistant for temperature ranges of 30○F ~ 150○F (-35○C ~ +66○C).
SPECIFICATIONS
-
APPLICATIONS
For offices, schools, hospitals, apartments, condo units, hotel/motel, residential, commercial and public buildings.
-
DOOR RANGES
1 ⅜” to 1-¾”.
-
BACKSET
2 ¾” standard or 2 ⅜” optional backset.
-
LATCH FACEPLATE
Standard 1 ⅛” x 2 ¼” for 2 ¾” backset.
Optional 1” x 2 ¼” for 2 ⅜” backset.
-
STRIKES
ASA Strike standard, T and full lip strike available on request.
-
ANSI STANDARDS
Certified ANSI / BHMA A156.2 Series 4000 Grade 1 requirements.
-
CLUTCH
Clutch technology allows turning of lever without retracting the latch, thus prolonging the life of the lock by reducing stress on the spindle and other parts.
-
CYLINDER
6-pin solid brass “Schlage C” keyway standard with two brass keys per lock.
-
PROXIMITY CARD (STANDARD)
2 pcs. included. Compatible with existing MIFARE infrastructures.
Operates at 13.56 MHz in accordance with ISO 14443A.
Inductive distance up to 1 3/16”.
-
RFID KEYFOB (OPTIONAL)
Operates at 13.56 MHz in accordance with ISO 14443A. Inductive distance up to 1 3/16”.
-
POWER SUPPLY
4 AA 1.5V Alkaline Batteries (Come standard in packaging).
-
BLUETOOTH CONNECTIVITY (OPTIONAL)
Lock can be managed / synced using the ExperienSmart app for both Apple & Android phones.(Bluetooth Receiver installation required).
-
INTERCHANGEABLE CORE (IC)
Interchangeable Core locks will accept compatible 6 or 7 pin cores with BEST and FALCON. Prefix “IC” before part number.
-
WEATHER RESISTANT
All models are weather-resistant for temperature ranges of -30○F ~ 150○F (-35○C ~ 66○C).
-
TOUCH SCREEN
Responds to human touch enabling convenient entrance or access to the programming menu. After the operation has been completed, the lock reverts to sleep mode.
https://www.cal-royal.com/component/opencart/p-548-cr6100-series
Installation Challenge Level
Challenging
Recommended for Experienced Installers
Company Info
Resources
Why Buy From Us?
Huge Inventory
Huge Inventory
No Hassle Returns
Satisfaction
Guaranteed
Guaranteed
News & Updates
Sign up to get the latest on sales, new releases and more …
