Exit Devices/Panic Bars
Panic Bars/Exit Devices and Trim for standard and fire-rated commercial doors, from PDQ, Von Duprin, Adams Rite, and Detex. Our products meet the requirements of the Buy American Act.
PDQ 4200 Rim Exit Device for 36" Door
$216.50
The PDQ 4200 Series offers a reliable and economical solution for compliance with life safety code requirements.
Available with matching door trim - choose from a Grip Pull with Thumbpiece or Lever. Includes standard Schlage SC1 cylinder. See photo.
Features
- Units are non-handed to facilitate easy field installation
- Meets requirements of the Buy American Act
Specs
- RAIL: Heavy gauge steel or stainless steel
- TOUCH PAD: Heavy gauge steel or stainless steel
- LATCH BOLT: Stainless steel dead locking / 3/4” throw Rim / 5/8” throw SVR
- PROJECTION: 2-5/8” projection
- HAND: Device and trim are non-handed
- DOGGING: Hex key dogging
- APPLICATION: Rim
- STILE WIDTH: 4-1/4” minimum
- DOOR THICKNESS: 1-3/4”
- DOOR WIDTH: For doors up to 3 foot wide
- FASTENERS: Fasteners furnished for wood and metal door applications / Sex nuts and bolts standard with fire labeled devices
- CERTIFICATION: U.L./U.L.C. listed for “Panic”, Complies with U.L. 10C and UBC 7.2 (1997)
- WARRANTY: Five (5) year limited factory warranty
Finishes
Satin Stainless Steel 630/US32D
Satin Chrome 626/US26D
Aluminum 695
Installation Challenge Level
Challenging
Recommended for Experienced Installers, but not rocket science.
Instructions & Templates
PDQ 6300 Rim Exit Device for 36" Door
$388.50
The PDQ 6300 Series offers superior durability in commercial applications while providing compliance with life safety code requirements.
Available with matching door trim - choose from a Grip Pull with Thumbpiece or Lever. Includes standard Schlage SC1 cylinder. See photo.
Features
- Units are non-handed to facilitate easy field installation
- Meets requirements of the Buy American Act
Specs
- RAIL: Extruded aluminum
- TOUCH PAD: Stainless steel
- LATCH BOLT: Stainless steel dead locking / 3/4” throw Rim / 5/8” throw SVR
- STRIKE: Roller strike standard for non-fire labeled devices
- PROJECTION: 3-1/8” projection / 1-5/8” projection when dogged
- HAND: Device and trim are non-handed
- DOGGING: Hex key dogging
- APPLICATION: Rim / Covers 161 prep
- STILE WIDTH: 4-1/4” minimum
- DOOR THICKNESS: 1-3/4”
-
DOOR WIDTH: Order 36" length for 2’10”- 3’0” door width maximum.
Order 48" length for over 3'-0" up to 4’0” door width maximum. - FASTENERS: Sex nuts and bolts standard
- CERTIFICATION: U.L./U.L.C. listed for “Panic”
- WARRANTY: Ten (10) year limited factory warranty
Finishes
Satin Stainless Steel 630/US32D
Installation Challenge Level
Challenging
Recommended for Experienced Installers, but not rocket science.
Instructions & Templates
PDQ 4200 Rim Exit Device for 36" Door - Fire Rated
$298.00
The PDQ 4200 Series offers a reliable and economical solution for compliance with life safety and fire code requirements.
Available with matching door trim - choose from a Grip Pull with Thumbpiece or Lever. Includes standard Schlage SC1 cylinder. See photo.
Features
- Units are non-handed to facilitate easy field installation
- Meets requirements of the Buy American Act
Specs
- RAIL: Heavy gauge steel or stainless steel
- TOUCH PAD: Heavy gauge steel or stainless steel
- LATCH BOLT: Stainless steel dead locking / 3/4” throw Rim / 5/8” throw SVR
- PROJECTION: 2-5/8” projection
- HAND: Device and trim are non-handed
- DOGGING: No dogging on fire labeled devices
- APPLICATION: Rim
- STILE WIDTH: 4-1/4” minimum
- DOOR THICKNESS: 1-3/4”
- DOOR WIDTH: For doors up to 3 foot wide
- FASTENERS: Fasteners furnished for wood and metal door applications / Sex nuts and bolts standard with fire labeled devices
- CERTIFICATION: U.L./U.L.C. listed for “Panic”, “Fire Exit hardware” labeled for up to 3 hour for 4’0” x 8’0” maximum single, 8’0” x 8’0” maximum pairs / Complies with U.L. 10C and UBC 7.2 (1997)
- WARRANTY: Five (5) year limited factory warranty
Finishes
Satin Stainless Steel 630/US32D
Installation Challenge Level
Challenging
Recommended for Experienced Installers, but not rocket science.
Instructions & Templates
PDQ 6300 Rim Exit Device for 36" Door - Fire Rated
$405.00
The PDQ 6300 Series offers superior durability in commercial applications while providing compliance with life safety and fire code requirements.
Available with matching door trim - choose from a Grip Pull with Thumbpiece or Lever. Includes standard Schlage SC1 cylinder. See photo.
Features
- Units are non-handed to facilitate easy field installation
- Meets requirements of the Buy American Act
Specs
- RAIL: Extruded aluminum
- TOUCH PAD: Stainless steel
- LATCH BOLT: Stainless steel dead locking / 3/4” throw Rim / 5/8” throw SVR
- STRIKE: Roller strike standard for non-fire labeled devices
- PROJECTION: 3-1/8” projection / 1-5/8” projection when dogged
- HAND: Device and trim are non-handed
- DOGGING: No dogging on fire labeled devices
- APPLICATION: Rim / Covers 161 prep
- STILE WIDTH: 4-1/4” minimum
- DOOR THICKNESS: 1-3/4”
- DOOR WIDTH: For doors up to 3 foot in width
- FASTENERS: Sex nuts and bolts standard
- CERTIFICATION: U.L./U.L.C. listed for “Panic”, “Fire Exit hardware” labeled for up to 3 hour for 4’0” x 8’0” maximum single, 8’0” x 8’0” maximum pairs / Complies with U.L. 10C and UBC 7.2 (1997)
- WARRANTY: Ten (10) year limited factory warranty - mechanical, One Year limited warranty electrical components.
Finishes
Satin Stainless Steel 630/US32D
Installation Challenge Level
Challenging
Recommended for Experienced Installers, but not rocket science.
Instructions & Templates
PDQ 4200 Rim Exit Device for 48" Door
$244.50
The PDQ 4200 Series offers a reliable and economical solution for compliance with life safety code requirements.
Available with matching door trim - choose from a Grip Pull with Thumbpiece or Lever. Includes standard Schlage SC1 cylinder. See photo.
Features
- Units are non-handed to facilitate easy field installation
- Meets requirements of the Buy American Act
Specs
- RAIL: Heavy gauge steel or stainless steel
- TOUCH PAD: Heavy gauge steel or stainless steel
- LATCH BOLT: Stainless steel dead locking / 3/4” throw Rim / 5/8” throw SVR
- PROJECTION: 2-5/8” projection
- HAND: Device and trim are non-handed
- DOGGING: Hex key dogging
- APPLICATION: Rim
- STILE WIDTH: 4-1/4” minimum
- DOOR THICKNESS: 1-3/4”
- DOOR WIDTH: For doors up to 4 foot wide
- FASTENERS: Fasteners furnished for wood and metal door applications / Sex nuts and bolts standard with fire labeled devices
- CERTIFICATION: U.L./U.L.C. listed for “Panic”, Complies with U.L. 10C and UBC 7.2 (1997)
- WARRANTY: Five (5) year limited factory warranty
Finishes
Satin Stainless Steel 630/US32D
Installation Challenge Level
Challenging
Recommended for Experienced Installers, but not rocket science.
Instructions & Templates
PDQ 6300 Rim Exit Device for 48" Door
$342.79
The PDQ 6200 Series offers superior durability in commercial applications while providing compliance with life safety code requirements.
Available with matching door trim - choose from a Grip Pull with Thumbpiece or Lever. Includes standard Schlage SC1 cylinder. See photo.
Features
- Units are non-handed to facilitate easy field installation
- Meets requirements of the Buy American Act
Specs
- RAIL: Extruded aluminum
- TOUCH PAD: Stainless steel
- LATCH BOLT: Stainless steel dead locking / 3/4” throw Rim / 5/8” throw SVR
- STRIKE: Roller strike standard for non-fire labeled devices
- PROJECTION: 3-1/8” projection / 1-5/8” projection when dogged
- HAND: Device and trim are non-handed
- DOGGING: Hex key dogging
- APPLICATION: Rim / Covers 161 prep
- STILE WIDTH: 4-1/4” minimum
- DOOR THICKNESS: 1-3/4”
- DOOR WIDTH: For up to 4 foot door width
- FASTENERS: Sex nuts and bolts standard
- CERTIFICATION: U.L./U.L.C. listed for “Panic”
- WARRANTY: Ten (10) year limited factory warranty
Finishes
Satin Stainless Steel 630/US32D
Installation Challenge Level
Challenging
Recommended for Experienced Installers, but not rocket science.
Instructions & Templates
PDQ 6300 Rim Exit Device for 48" Door - Fire Rated
$498.60
The PDQ 6200 Series offers superior durability in commercial applications while providing compliance with life safety and fire code requirements.
Available with matching door trim - choose from a Grip Pull with Thumbpiece or Lever. Includes standard Schlage SC1 cylinder. See photo.
Features
- Units are non-handed to facilitate easy field installation
- Meets requirements of the Buy American Act
Specs
- RAIL: Extruded aluminum
- TOUCH PAD: Stainless steel
- LATCH BOLT: Stainless steel dead locking / 3/4” throw Rim / 5/8” throw SVR
- STRIKE: Roller strike standard for non-fire labeled devices
- PROJECTION: 3-1/8” projection / 1-5/8” projection when dogged
- HAND: Device and trim are non-handed
- DOGGING: No dogging on fire labeled devices
- APPLICATION: Rim / Covers 161 prep
- STILE WIDTH: 4-1/4” minimum
- DOOR THICKNESS: 1-3/4”
- DOOR WIDTH: For doors up to 4 foot in width
- FASTENERS: Sex nuts and bolts standard
- CERTIFICATION: U.L./U.L.C. listed for “Panic”, “Fire Exit hardware” labeled for up to 3 hour for 4’0” x 8’0” maximum single, 8’0” x 8’0” maximum pairs / Complies with U.L. 10C and UBC 7.2 (1997)
- WARRANTY: Ten (10) year limited factory warranty - mechanical, One Year limited warranty electrical components.
Finishes
Satin Stainless Steel 630/US32D
Installation Challenge Level
Challenging
Recommended for Experienced Installers, but not rocket science.
Instructions & Templates
Adams Rite 8800 Rim Exit Device for 36" Glass Doors
$574.00
Adams Rite Rim Exit Device for narrow stile glass doors.
Features
- Patented “Starwheel” bolt interlocks door to frame
- Strong, durable construction for a high level of security
- Easy to install
- Unobtrusive design for clean sight lines
- Pushbar clad or anodized, not plated
Specs
- UL 305 Panic Hardware
- ANSI/BHMA A156.3 Grade 1
- Standard width bars can be field cut to the next smallest opening width
- Door thickness: Suits 1-3/4-inches standard, up to 2-1/4-inches
- Stile Width: Minimum 2-inches Stile. Fits Narrow, Medium and Wide Stile aluminum doors
- Projection: 2-5/8-inches when fully projected, 1-5/8-inches when dogged
- Materials: Pushbar made of extruded aluminum
- Dogging: Standard dogging with hex key
- Fasteners: Standard self-tapping screws
- California State Fire Marshall
- New York City MEA
Finishes
Satin Aluminum 628/US28
Bronze 695/SP313
Installation Challenge Level
Easy
Anyone who can read instructions and use basic tools can install this product.
Instructions & Templates
Adams Rite 8800 Rim Exit Device for 48" Glass Doors
$574.00
Adams Rite Rim Exit Device for narrow stile glass doors.
Features
- Patented “Starwheel” bolt interlocks door to frame
- Strong, durable construction for a high level of security
- Easy to install
- Unobtrusive design for clean sight lines
- Pushbar clad or anodized, not plated
Specs
- UL 305 Panic Hardware
- ANSI/BHMA A156.3 Grade 1
- Standard width bars can be field cut to the next smallest opening width
- Door thickness: Suits 1-3/4-inches standard, up to 2-1/4-inches
- Stile Width: Minimum 2-inch Stile. Fits Narrow, Medium and Wide Stile aluminum doors
- Projection: 2-5/8-inches when fully projected, 1-5/8-inches when dogged
- Materials: Pushbar made of extruded aluminum
- Dogging: Standard dogging with hex key
- Fasteners: Standard self-tapping screws
- California State Fire Marshall
- New York City MEA
Finishes
Satin Aluminum 628/US28
Bronze 695/SP313
Installation Challenge Level
Easy
Anyone who can read instructions and use basic tools can install this product.
Instructions & Templates
PDQ 4200 Surface Vertical Rod Exit Device Less Bottom Rod
$315.00
The PDQ 4200 Series offers a reliable and economical solution for compliance with life safety code requirements. The PDQ 4200 Series Surface vertical rod devices feature top Pullman latch bolt which is dead locking.
Available with matching door trim - choose from a Grip Pull with Thumbpiece or Lever. Includes standard Schlage SC1 cylinder. See photo.
Features
- Units are non-handed to facilitate easy field installation
- Meets requirements of the Buy American Act
Specs
- RAIL: Heavy gauge steel or stainless steel
- TOUCH PAD: Heavy gauge steel or stainless steel
- LATCHES: Top Latch — Pullman with dead latching 5/8” (16mm) throw
- BACKSET: 2-3/4" backset, Supplied standard for 161 prep with door gap of 1/8"
- PROJECTION: 2-5/8” projection
- HAND: Device is non-handed
- DOGGING: Hex key dogging
- MINIMUM STILE WIDTH: 2-1/2"
- DOOR THICKNESS: 1-3/4”
- DOOR WIDTH: Supplied standard for 3 ft doors
- FASTENERS: Fasteners furnished for wood and metal door applications. Sex nuts standard with fire listed devices
- CERTIFICATION: UL/ULC 305 listed for “Panic
Finishes
Satin Stainless Steel 630/US32D
Installation Challenge Level
Challenging
Recommended for Experienced Installers, but not rocket science.
Instructions & Templates
PDQ 6300 Surface Vertical Rod Exit Device Less Bottom Rod
$605.00
The PDQ 6300 Series offers superior durability in commercial applications while providing compliance with life safety and fire code requirements. The PDQ 6200 Series surface vertical rod devices feature top pullman latch bolts that are dead locking where applicable.
Available with matching door trim - choose from a Grip Pull with Thumbpiece or Lever. Includes standard Schlage SC1 cylinder. See photo.
Features
- Units are non-handed to facilitate easy field installation
- Meets requirements of the Buy American Act
Specs
- RAIL: Extruded aluminum
- TOUCH PAD: Stainless steel
- LATCH BOLT: Stainless steel dead locking / 3/4” throw Rim / 5/8” throw SVR
- STRIKE: Roller strike standard for non-fire labeled devices
- PROJECTION: 3-1/8” projection / 1-5/8” projection when dogged
- HAND: Device and trim are non-handed
- DOGGING: Hex key dogging
- APPLICATION: Surface vertical rod (8’0” tall door standard) / Covers 161 prep
- STILE WIDTH: 4-1/4” minimum
- DOOR THICKNESS: 1-3/4”
- DOOR WIDTH: For 2’10”- 3’0” door width maximum
- FASTENERS: Sex nuts and bolts standard
- CERTIFICATION: U.L./U.L.C. listed for “Panic”, “Fire Exit hardware” labeled for up to 3 hour for 4’0” x 8’0” maximum single, 8’0” x 8’0” maximum pairs / Complies with U.L. 10C and UBC 7.2 (1997)
- WARRANTY: Ten (10) year limited factory warranty
Finishes
Satin Stainless Steel 630/US32D
Installation Challenge Level
Challenging
Recommended for Experienced Installers, but not rocket science.
Instructions & Templates
PDQ 4200 Surface Vertical Rod Exit Device
$296.00
The PDQ 4200 Series offers a reliable and economical solution for compliance with life safety code requirements. The PDQ 4200 Series Surface vertical rod devices feature top and bottom Pullman latch bolts which are dead locking.
Available with matching door trim - choose from a Grip Pull with Thumbpiece or Lever. Includes standard Schlage SC1 cylinder. See photo.
Features
- Units are non-handed to facilitate easy field installation
- Meets requirements of the Buy American Act
Specs
- RAIL: Heavy gauge steel or stainless steel
- TOUCH PAD: Heavy gauge steel or stainless steel
- LATCHES: Top Latch — Pullman with dead latching 5/8” (16mm) throw, Bottom Latch — Pullman with 5/8” (16mm) throw, held retracted during door swing
- BACKSET: 2-3/4" backset, Supplied standard for 161 prep with door gap of 1/8"
- PROJECTION: 2-5/8” projection
- HAND: Device is non-handed
- DOGGING: Hex key dogging
- MINIMUM STILE WIDTH: 2-1/2"
- DOOR THICKNESS: 1-3/4”
- DOOR WIDTH: For doors up to 3 foot in width
- FASTENERS: Fasteners furnished for wood and metal door applications. Sex nuts standard with fire listed devices
- CERTIFICATION: UL/ULC 305 listed for “Panic”
Finishes
Satin Stainless Steel 630/US32D
Installation Challenge Level
Challenging
Recommended for Experienced Installers, but not rocket science.
Instructions & Templates
PDQ 6300 Surface Vertical Rod Exit Device
$403.50
The PDQ 6200 Series offers superior durability in commercial applications while providing compliance with life safety and fire code requirements. The PDQ 6200 Series vertical rod devices feature top and bottom pullman latch bolts that are dead locking where applicable.
Available with matching door trim - choose from a Grip Pull with Thumbpiece or Lever. Includes standard Schlage SC1 cylinder. See photo.
Features
- Units are non-handed to facilitate easy field installation
- Meets requirements of the Buy American Act
Specs
- RAIL: Extruded aluminum
- TOUCH PAD: Stainless steel
- LATCH BOLT: Stainless steel dead locking / 3/4” throw Rim / 5/8” throw SVR
- STRIKE: Roller strike standard for non-fire labeled devices
- PROJECTION: 3-1/8” projection / 1-5/8” projection when dogged
- HAND: Device and trim are non-handed
- DOGGING: Hex key dogging
- APPLICATION: Surface vertical rod (8’0” tall door standard) / Covers 161 prep
- STILE WIDTH: 4-1/4” minimum
- DOOR THICKNESS: 1-3/4”
- DOOR WIDTH: For 2’10”- 3’0” door width maximum
- FASTENERS: Sex nuts and bolts standard
- CERTIFICATION: U.L./U.L.C. listed for “Panic”
- WARRANTY: Ten (10) year limited factory warranty
Finishes
Satin Stainless Steel 630/US32D
Installation Challenge Level
Challenging
Recommended for Experienced Installers, but not rocket science.
Instructions & Templates
PDQ 4200 Surface Vertical Rod Exit Device - for 48" Door
$332.00
The PDQ 4200 Series offers a reliable and economical solution for compliance with life safety and fire code requirements. The PDQ 4200 Series Surface vertical rod devices feature top and bottom Pullman latch bolts which are dead locking.
Available with matching door trim - choose from a Grip Pull with Thumbpiece or Lever. Includes standard Schlage SC1 cylinder. See photo.
Features
- Units are non-handed to facilitate easy field installation
- Meets requirements of the Buy American Act
Specs
- RAIL: Heavy gauge steel or stainless steel
- TOUCH PAD: Heavy gauge steel or stainless steel
- LATCHES: Top Latch — Pullman with dead latching 5/8” (16mm) throw, Bottom Latch — Pullman with 5/8” (16mm) throw, held retracted during door swing
- BACKSET: 2-3/4" backset, Supplied standard for 161 prep with door gap of 1/8"
- PROJECTION: 2-5/8” projection
- HAND: Device is non-handed
- DOGGING: No dogging on fire listed devices
- MINIMUM STILE WIDTH: 2-1/2"
- DOOR THICKNESS: 1-3/4”
- DOOR WIDTH: For doors up to 4 foot in width
- FASTENERS: Fasteners furnished for wood and metal door applications. Sex nuts standard with fire listed devices
- CERTIFICATION: UL/ULC 305 listed for “Panic”,
- Complies with ADA (Americans with Disabilities Act) and ICC/ANSI 117.1 for Accessible and Usable Buildings
Finishes
Satin Stainless Steel 630/US32D
Installation Challenge Level
Challenging
Recommended for Experienced Installers, but not rocket science.
Instructions & Templates
PDQ 6300 Surface Vertical Rod Exit Device - Fire Rated
$797.00
The PDQ 6200 Series offers superior durability in commercial applications while providing compliance with life safety and fire code requirements. The PDQ 6200 Series vertical rod devices feature top and bottom pullman latch bolts that are dead locking where applicable.
Available with matching door trim - choose from a Grip Pull with Thumbpiece or Lever. Includes standard Schlage SC1 cylinder. See photo.
Features
- Units are non-handed to facilitate easy field installation
- Meets requirements of the Buy American Act
Specs
- RAIL: Extruded aluminum
- TOUCH PAD: Stainless steel
- LATCH BOLT: Stainless steel dead locking / 3/4” throw Rim / 5/8” throw SVR
- STRIKE: Roller strike standard for non-fire labeled devices
- PROJECTION: 3-1/8” projection / 1-5/8” projection when dogged
- HAND: Device and trim are non-handed
- DOGGING: No dogging on fire labeled devices
- APPLICATION: Surface vertical rod (8’0” tall door standard) / Covers 161 prep
- STILE WIDTH: 4-1/4” minimum
- DOOR THICKNESS: 1-3/4”
- DOOR WIDTH: For 2’10”- 3’0” door width maximum
- FASTENERS: Sex nuts and bolts standard
- CERTIFICATION: U.L./U.L.C. listed for “Panic”, “Fire Exit hardware” labeled for up to 3 hour for 4’0” x 8’0” maximum single, 8’0” x 8’0” maximum pairs / Complies with U.L. 10C and UBC 7.2 (1997)
- WARRANTY: Ten (10) year limited factory warranty
Finishes
Satin Stainless Steel 630/US32D
Installation Challenge Level
Challenging
Recommended for Experienced Installers, but not rocket science.
Instructions & Templates
Von Duprin 2670 Guard-X Alarmed Exit Device
$610.50
GUARD-X provides secure, alarmed code-compliant protection for secondary exits. GUARD-X exit alarm lock readily identifies the door on which it is mounted as an emergency exit and secures the opening against unauthorized use. It is ideal for deterring theft in restaurants and retail establishments such as: discount, grocery, drug, clothing and sporting goods stores.
Features
- Heavy-Duty Design
- Stainless steel deadbolt
- Tested to withstand up to 1600 pounds of force
- Requires key to reset after unauthorized exit
- 100-decibel alarm
- Armed indicator light
- Complies with NFPA 101® Life Safety Code
- UL Listed
- Non-handed
- Schlage SC-1 key cylinder included
Finishes
Satin Aluminum 628/US28
Installation Challenge Level
Challenging
Recommended for Experienced Installers, but not rocket science.
Instructions & Templates
Detex V40xEB Alarmed Exit Device for 36" Doors
$513.00
The V40xEB is designed for primary and secondary exits that require an alarmed panic device. The 100dB alarm will sound when someone attempts to exit, alerting management to the unauthorized exit. The V40xEB provides security while meeting all life safety concerns, offering an exceptional value.
Features
- Powered by standard 9-volt battery
- Patented back plate and plastic strike locator provide paperless template for perfect alignment with door and frame
- Stainless steel, 3/4" deadlocking Pullman-type latch bolt
- Heavy-duty angled end-cap deflects damage away from device
- 100 decibel alarm
- Heavy-duty ribbed aluminum rail extrusion
- State-of-art electronics offer reliable security and instantaneous alarm
- Visual and audible arming indicators
- Schlage SC-1 key cylinder included
Specs
- Door Types - Wood, Hollow Metal and Fiberglass
- Door Thickness - Fits standard 1-3/4" - 2-1/4" doors
- Single Door Stile - Fits 3-1/2” minimum stile doors with 99 surface strike (Std.)
- Machine and Self-Drilling Screws (Std.)
- Actual finish may vary from photo
Finishes
Satin Aluminum 628/US28
Black Anodized Aluminum 711/315AN
Installation Challenge Level
Challenging
Recommended for Experienced Installers, but not rocket science.
Instructions & Templates
Detex V40xEB Alarmed Exit Device for 48" Doors
$587.00
The V40xEB is designed for primary and secondary exits that require an alarmed panic device. The 100dB alarm will sound when someone attempts to exit, alerting management to the unauthorized exit. The V40xEB provides security while meeting all life safety concerns, offering an exceptional value.
Features
- Powered by standard 9-volt battery
- Patented back plate and plastic strike locator provide paperless template for perfect alignment with door and frame
- Stainless steel, 3/4" deadlocking Pullman-type latch bolt
- Heavy-duty angled end-cap deflects damage away from device
- 100 decibel alarm
- Heavy-duty ribbed aluminum rail extrusion
- State-of-art electronics offer reliable security and instantaneous alarm
- Visual and audible arming indicators
- Schlage SC-1 key cylinder included
Specs
- Door Types - Wood, Hollow Metal and Fiberglass
- Door Thickness - Fits standard 1-3/4" - 2-1/4" doors
- Single Door Stile - Fits 3-1/2” minimum stile doors with 99 surface strike (Std.)
- Machine and Self-Drilling Screws (Std.)
- Actual finish may vary from photo
Finish
Satin Aluminum 628/US28
Installation Challenge Level
Challenging
Recommended for Experienced Installers, but not rocket science.
Instructions & Templates
PDQ 4200 Exit Device Trim - Lever
$81.00
This 4200 Series trim component provides an outside lever for PDQ 4200 Series Rim and Surface Vertical Rod Exit Devices.
Includes standard Schlage SC1 cylinders.
Finishes
Satin Chrome Plated 626/US32D
Installation Challenge Level
Challenging
Recommended for Experienced Installers, but not rocket science.
PDQ 6300 Exit Device Trim - Lever
$134.00
This 6300 series trim component provides an outside lever for PDQ 6200 Series Rim and Surface Vertical Rod Exit Devices.
Includes standard Schlage SC1 cylinder.
Finishes
Satin Chrome Plated 626/US32D
Installation Challenge Level
Challenging
Recommended for Experienced Installers, but not rocket science.
PDQ 4200 Exit Device Trim - Grip Pull with Thumbpiece
$84.00
This PDQ 4200 Series trim component provides grip pull with Thumbpiece for PDQ 4200 Series Rim and Surface Vertical Rod Exit Devices.
Includes standard Schlage SC1 cylinder.
Finishes
Satin Stainless Steel 630/US32D
Installation Challenge Level
Challenging Recommended for Experienced Installers, but not rocket science.
PDQ 6300 Exit Device Trim - Grip Pull with Thumbpiece
$254.00
This PDQ 6200 Series trim component provides grip pull with thumbpiece for PDQ 6200 Series Rim and Surface Vertical Rod Exit Devices.
Includes standard Schlage SC1 cylinder.
FUNCTION
- Entrance by thumb piece. Key locks or unlocks thumb piece (classroom thumb piece)
Finishes
Satin Stainless Steel 630/US32D
Installation Challenge Level
Challenging
Recommended for Experienced Installers, but not rocket science.
Cal-Royal A7700 RIM TYPE EXIT DEVICES for 36" Doors.
$354.00
A7700 & AF7700 ADA SERIES
For use in institutions, schools, universities, commercial buildings where heavy duty reliable operation is a requirement.
-
- ANSI A156.3, GRADE 1 heavy duty exit device in surface vertical rod and rim designs.
- Retrofits Von Duprin 99 & 98 Series using 7700 Escutcheon trim
- Rail assemblies are heavy duty extruded aluminum body with stainless steel push pad and end caps are made of brass, bronze or stainless steel. Rail travels in direction of the door swing.
- Trims are thru bolted for additional security.
- Conforms & Meets ADA Regulations.
- Americans with Disability Act (ADA) Compliant, 5 lbs. opening force.
- UL Listed for Panic and UL10C, UBC 7-2-1997 codes.
- UL Listed for Fire Exit Hardware. 3 hours.
- (A) label rating on pairs of doors up to 8’0″ x 8’0″ swinging in same or opposite directions.
- Uncompromising security and safety in single and double fire exit doors.
- Chassis mounted unit construction. Rim and vertical rod devices are non-handed and easily reversible.
- Available in many different functions. Lever and escutcheon trims are grade 1 construction with clutch on rose trims. Escutcheon trims are rigid and cover 161 cut out.
- For Doors - 1 ¾" thick standard optional 2 ¼” thick. 4 ½" minimum stile width for single or double door application using standard 938 strike and pull or lever, thumbpiece, and escutcheon trim. 2-3/4" backset.
- Chassis - Non-Ferrous Alloy (Panic Grade), Steel (Fire Grade).
- Cover - Non-Ferrous plated material. Covers stock hollow metal doors with 161 cut out.
- Mounting - Furnished with wood and machine screws. Available thru-bolts on request. Thru bolts are included and standard packaging on fire-rated devices.
- End Cap - Brass, Bronze, or Stainless Steel construction.
- Alarm - Available. Prefix NALRM before PART#.
- Hand - Non-handed, center hub for 2 3/4" backset.
- Latch Bolt - Stainless steel ¾" throw with an anti-pick feature.
- Spring - Stainless steel throughout.
- ANSI Standard - A156.3, Grade 1.
- Rail Assembly - Heavy gauge extruded aluminum body with stainless steel push pad.
- Dogging Feature - Allen-type key furnished standard on non-fire labeled devices.
- Mullion - Available.
- UL and ULC Listed - A7700 Series for panic. AF7700 Series for fire exit hardware for all types of 4' x 8' single doors and 8' x 8' double doors for up to 3 hours fire labeled installations, conforms to standards UL10C and UBC 7-2-1997 codes.
- Strike - 938 packed standard.
- Finish - Architectural plated finishes.
- Electronic Functions - (ELR) Electrical Latch Retraction and RX & LX Signal Switch available
- Anti-Microbial Coating - Available on US32D only. Use part # ANTB-EXIT
Options
- Alarm
- Electrified
- Delayed Egress
Suggested Architect's Specifications
- All exit devices shall be of touch bar design with smooth operation and be operative over 2/3 of the door's clear opening width.
- All exit devices must be listed under "Panic Hardware" in the Accident Equipment List of Underwriters' Laboratories, Inc. Where labeled doors are used as exits, they must be equipped with labeled Fire Exit Hardware and UL10C, UBC-7-2-1997 codes.
- All springs shall be of stainless steel throughout.
- All exit devices shall be of chassis mounted unit construction.
- All exit devices shall be ANSI A156.3, Grade 1.
Dimension
Minimum Stile Requirements
Installation Challenge Level
Challenging
Recommended for Experienced Installers, but not rocket science.
- Template - 7700 Panic Rim Type Exit Device
- Template - F7700 Panic Rim Type Exit Device
- Template - ESC7700 Trim
INSTALLATION INSTRUCTIONS
Cal-Royal A7700F RIM TYPE EXIT DEVICES for 36" Doors - FIRE RATED
$416.00
For use in institutions, schools, universities, commercial buildings where heavy duty reliable operation is a requirement.
-
A7700 & AF7700 ADA SERIES
- ANSI A156.3, GRADE 1 heavy duty exit device in surface vertical rod and rim designs.
- Retrofits Von Duprin 99 & 98 Series using 7700 Escutcheon trim
- Rail assemblies are heavy duty extruded aluminum body with stainless steel push pad and end caps are made of brass, bronze or stainless steel. Rail travels in direction of the door swing.
- Trims are thru bolted for additional security.
- Conforms & Meets ADA Regulations.
- Americans with Disability Act (ADA) Compliant, 5 lbs. opening force.
- UL Listed for Panic and UL10C, UBC 7-2-1997 codes.
- UL Listed for Fire Exit Hardware. 3 hours.
- (A) label rating on pairs of doors up to 8’0″ x 8’0″ swinging in same or opposite directions.
- Uncompromising security and safety in single and double fire exit doors.
- Chassis mounted unit construction. Rim and vertical rod devices are non-handed and easily reversible.
- Available in many different functions. Lever and escutcheon trims are grade 1 construction with clutch on rose trims. Escutcheon trims are rigid and cover 161 cut out.
- For Doors - 1 ¾" thick standard optional 2 ¼” thick. 4 ½" minimum stile width for single or double door application using standard 938 strike and pull or lever, thumbpiece, and escutcheon trim. 2-3/4" backset.
- Chassis - Non-Ferrous Alloy (Panic Grade), Steel (Fire Grade).
- Cover - Non-Ferrous plated material. Covers stock hollow metal doors with 161 cut out.
- Mounting - Furnished with wood and machine screws. Available thru-bolts on request. Thru bolts are included and standard packaging on fire-rated devices.
- End Cap - Brass, Bronze, or Stainless Steel construction.
- Alarm - Available. Prefix NALRM before PART#.
- Hand - Non-handed, center hub for 2 3/4" backset.
- Latch Bolt - Stainless steel ¾" throw with an anti-pick feature.
- Spring - Stainless steel throughout.
- ANSI Standard - A156.3, Grade 1.
- Rail Assembly - Heavy gauge extruded aluminum body with stainless steel push pad.
- Dogging Feature - Allen-type key furnished standard on non-fire labeled devices.
- Mullion - Available.
- UL and ULC Listed - A7700 Series for panic. AF7700 Series for fire exit hardware for all types of 4' x 8' single doors and 8' x 8' double doors for up to 3 hours fire labeled installations, conforms to standards UL10C and UBC 7-2-1997 codes.
- Strike - 938 packed standard.
- Finish - Architectural plated finishes.
- Electronic Functions - (ELR) Electrical Latch Retraction and RX & LX Signal Switch available
- Anti-Microbial Coating - Available on US32D only. Use part # ANTB-EXIT
Options
- Alarm
- Electrified
- Delayed Egress
Suggested Architect's Specifications
- All exit devices shall be of touch bar design with smooth operation and be operative over 2/3 of the door's clear opening width.
- All exit devices must be listed under "Panic Hardware" in the Accident Equipment List of Underwriters' Laboratories, Inc. Where labeled doors are used as exits, they must be equipped with labeled Fire Exit Hardware and UL10C, UBC-7-2-1997 codes.
- All springs shall be of stainless steel throughout.
- All exit devices shall be of chassis mounted unit construction.
- All exit devices shall be ANSI A156.3, Grade 1.
Dimension
Minimum Stile Requirements
- Template - 7700 Panic Rim Type Exit Device
- Template - F7700 Panic Rim Type Exit Device
- Template - ESC7700 Trim
INSTALLATION INSTRUCTIONS
Cal-Royal 5000 & F5000 Fire Rated Series Rim Exit Device
$111.00
RIM TYPE EXIT DEVICES. Uncompromising security and safety in single and double fire exit doors.
-
5000 & F5000 SERIES
- ANSI A156.3, GRADE 1 Heavy Duty Rim Exit Device
- UL Listed for Panic and UL10C, UBC 7-2-1997 codes.
- UL Listed for Fire Exit Hardware. 3 hours.
- (A) label rating on pairs of doors up to 8’0″ x 8’0″ swinging in same or opposite directions.
- Chassis mounted unit construction.
- Available in standard functions. Lever and knob trims have an optional clutch freewheeling mechanism. Rose covers 161 cut out.
- For Doors - 1 ¾" thick standard. 3 ¾" minimum stile width for single or double door application using standard 938 strike and pull or lever trims.
- Chassis - Steel (Panic & Fire Grade)
- Cover - Covers stock hollow metal doors with 161 cut out
- Mounting - Furnished standard with wood and machine screws. Available with thru-bolts on request. Thru bolts are standard packaging on fire-rated devices.
- End Cap - Steel construction
- Hand - Non-Handed, center hub.
- Latch Bolt - Stainless steel ¾" throw
- Spring - Steel throughout
- ANSI Standard - A156.3, Grade 1
- Rail Assembly - Heavy gauge steel, painted.
- Strike - 938 packed standard.
- Dogging Feature - Allen-type key furnished standard on non-fire labeled devices.
- Mullion - Available.
- UL and ULC Listed - 5000 Series for panic. F5000 Series for fire exit hardware for all types of 3' x 7' single doors and 6' x 7' double doors for up to 3-hour fire labeled installations, conforms to standards UL10C and UBC 7-2-1997 codes.
- Finish - Aluminum (ALUM), Stainless Steel (US32D)
- Anti-Microbial Coating - Available on US32D only. Use part # ANTB-EXIT
Suggested Architect’s Specifications
- All exit devices shall be of touch bar design with smooth operation and be operative over ⅔ of the door’s clear opening width
- All exit devices must be listed under “Panic Hardware” in the Accident Equipment List of Underwriters’ Laboratories, Inc. where labeled doors are used as exits, they must be equipped with labeled Fire Exit Hardware and UL10C, UBC 7-2-1997 codes
- All exit devices shall be of chassis mounted unit construction
Dimensions
Minimum Stile Requirements
Template and Installation Instructions
- Template - 5000NL, Pull and Rim Cylinder
- Template - Strike 254 Overlapping Strike (5000)
- Template - 5000 Series Head Assembly
- TEMPLATE FOR 5000 SERIES RIM & SVR EXIT DEVICE
- Installation Instructions - F5000EO RIM EXIT DEVICE
- Installation Instructions - 5000EO Rim Exit Device
- Installation Intructions & Template - CLU6000L
- Installation Instructions - 8000L Lever Design
- Installation Instructions - 8000K Knob Design
INSTALLATION CHALLENGE LEVEL
Challenging
Recommended for Experienced Installers, but not rocket science.
Cal-Royal 5000V & F5000V Series
$163.00
VERTICAL ROD TYPE EXIT DEVICES. Uncompromising security and safety in single and double fire exit doors
- ANSI A156.3, GRADE 1 Heavy Duty exit device in surface vertical rod and rim designs
- Lifetime Warranty
- UL listed for panic and ULC10C, UBC 7-2-1997 Codes
- UL Listed for Fire Exit Hardware. 3 Hours
- Chassis mounted unit construction
- Optional Mullion
- Available in standard functions. Lever and knob trims have an optional clutch freewheeling mechanism
- Architectural plated finishes available
- For Doors - 1-3/4" thick standard. 3-3/4" minimum stile width for single door application. 3-1/2" minimum stile width required for double door application. Lever and knob trims available
- Chassis - Steel (Panic Grade), steel (Fire Grade)
- Cover - Non-ferrous plated material. Covers stock hollow metal doors with 161 cutout
- Mounting - Furnished standard with wood and machine screws. Thru-bolts are standard packaging for fire-rated devices
- End Cap - Steel Construction
- Hand - Non-Handed
- Latch Bolt, Spring - Stainless Steel
- ANSI Standard - A156.3, Grade 1
- Rail Assembly - Heavy gauge steel, painted
- Strike - See Strike page.
- Dogging Feature - 5mm Allen-type key furnished standard on non-fire labeled devices
- UL and ULC Listed - 5000V Series for Panic. F5000V Series for fire exit hardware for all types of 6' x 7' double doors for up to 3-hour fire labeled installations, conforms to standards UL10C and UBC 7-2-1997 codes
- Finish - Aluminum, US32D (Stainless Steel)
- Door Size - 5000V3684 and F5000V3684 for 36" x 84" doors
Suggested Architect’s Specifications
- All exit devices shall be of touch bar design with smooth operation and be operative over ⅔ of the door’s clear opening width
- All exit devices must be listed under “Panic Hardware” in the Accident Equipment List of Underwriters’ Laboratories, Inc. Where labeled doors are used as exits, they must be equipped with labeled Fire Exit
- Hardware and UL10C, UBC 7-2-1997 codes
- All exit devices shall be of chassis mounted unit construction
Dimensions
Installation Instructions & Templates:
- Template – 5000NL, Pull and Rim Cylinder
- Template – 5000V Panic Vertical Rod Exit Device
- Template – Strike 254 Overlapping Strike (5000)
- Template for 5000 Series Rim & SVR Exit Device
- Template – 5000 Series Head Assembly
- Installation Instructions – 5000V Surface Vertical Rod
- Installation Instructions – F5000V Surface Vertical Rod
- Installation Intructions & Template – CLU6000L
- Installation Instructions – 8000L Lever Design
- Installation Instructions – 8000K Knob Design
Challenging
Recommended for Experienced Installers
Cal-Royal GLS7700 & FGLS7700 Series
$398.00
GLS7700 & FGLS7700 SERIES
RIM TYPE, NARROW STILE EXIT DEVICES
For use in institutions, schools, universities, commercial buildings where heavy duty reliable operation is a requirement.
-
- ANSI A156.3, GRADE 1 heavy duty exit device
- Conforms to ANSI/UL10C, ANSI/UL305 Standards
- For Doors: Wood, Metal, or Aluminum Glass doors with 1 ¾” minimum stile width, 1 ¾” thickness for single or double door application.
- Chassis: Non-Ferrous Alloy (Panic Grade)
- Cover: Non-ferrous plated material
- Mounting: Furnished with wood and machine screws. Thru bolts available upon request.
- End Cap: Brass, Bronze, or Stainless Steel construction.
- Alarm: Available for 36" bar only. Prefix NALRM before PART#
- Hand: Non-handed
- Latch Bolt: Stainless Steel 3/4" throw
- Spring: Stainless Steel throughout
- ANSI Standard: A156.3, Grade 1
- Rail Assembly: Heavy gauge extruded aluminum body with Stainless Steel push pad
- Strikes: 246 packed standard. Optional 247 strike. (See strike page)
- Dogging Feature: Available for 36" bar only. Allen-type key furnished standard
- Mullion: Available
- UL and ULC Listed: GLS7700 Series for Panic & Safety, FGLS7700 Series for all types 4' x 8' single doors and 8' x 8' double doors for up to 3-hour fire labeled installations. Conforms to ANIS/UL10C, ANSI/UL305 Standards
- Finish: Architectural plated finishes.
- Electronic Functions: (ELR) Electrical Latch Retraction and RX & LX Signal Switch available
- Anti-Microbial Coating - Available on US32D only. Use part # ANTB-EXIT
Dimensions
INSTALLATION INSTRUCTIONS
Challenging
Recommended for Experienced Installers but not rocket science
Cal-Royal A7700 Accessories -Outside Trim CLUTCH CYLINDRICAL LEVER
$121.00
COMPATIBLE WITH: Cal-Royal 7700 Series Exit Device, Cal-Royal 5000 Series Exit Device
Non-Handed Grade 1 (Clutch Style)
Cylindrical body hardened steel heavy duty tailpiece. For 1 ¾” and 2 ¼” doors.
Prefix “THI” before Part # for 2 ¼” door thickness.
Available for fire and non-fire rated rim and vertical rod exit devices.
Rose diameter 3 ½”, lever length 4 ¾”. Fits and covers 161 cutout.
Finishes: US32D, US26D
INCLUDES GRADE 304SS LEVER AND ROSE
Installation Challenge Level
Challenging
Recommended for Experienced Installers, but not rocket science.
Cal-Royal 7700 Panic Device Accessories - RIGID LEVER ESCUTCHEON
$150.00
CONSTRUCTION
• Rigid, non-clutch mechanism
• Double heavy duty spring support to prevent
sagging and enhance operation
• Grade 1, thru-bolted design. Non-handed design.
Easily field reversible
• Hardened steel heavy duty tailpiece. Available
for fire and non-fire rated rim and vertical rod exit
devices
• Standard 6-Pin Schlage “C” Mortise Cylinder
included
DOOR THICKNESS
Standard 1 ¾”. For 2 ¼” thick door use additional
Part # TAIL3
ESCUTCHEON DIMENSIONS
2 ¾” width X 10 ¼” length. Lever length: 4 ¾”.
Fits and covers 2 ⅛” 161 cutout
Installation Challenge Level
Challenging
Recommended for Experienced Installers, but not rocket science.
Cal-Royal Mechanical Easy Code Change Trim only
$267.00
Cal-Royal Mechanical Easy Code Change EXIT DEVICE TRIM ONLY for Rim and Surface Vertical Rods
Outside Trim for CAL-ROYAL 2200, 6600, 7700 and 9800 Series Rim and Surface Vertical Rods
Operated by lever from outside and when push pad is depressed, except outside has to enter a pre-programmed code on the keypad in order to retract the latch upon turning the lever. For use with 2200, 6600, 7700 and 9800 Series Rim and Surface Vertical Rods.
Default Function: Storeroom
Optional Function: Passage Mode
Finish: Satin Chrome (US26D)
Door Thickness: 1 3⁄4” - 2”
Catalogue page-crcode200-series
Installation Challenge Level
Challenging
Recommended for Experienced Installers.
PDQ 6400V Narrow Stile Surface Vertical Rod
$595.00
-
6400V Series - Surface Vertical Rod - Narrow Stile
Narrow Stile | 6400V
- Featuring a cast chassis for increased strength
- Cush spring that quiets operation in both directions
- Compression spring guarantees smooth touch bar return
- Heavy-duty flush end cap provides pry resistance
- Available in 6 finishes: 605(US3), 606(US4), 613(US10B), 622(US19), 626(US26D), 630(US32D)
- Patent-pending design
CERTIFICATIONS:
Ensure top-tier compliance and safety with the 6400V SVR Exit Device. This narrow stile SVR exit device holds the following certifications:
- UL 305 certified
- It’s UL 10C and CAN/ULC-S104 listed for 3-hour fire doors, accommodating double doors up to 8' x 8' (LBR), or 8' x 10' (single or double egress pair)
- Certified to ANSI/BHMA A156.3 Grade 1 standards, it meets rigorous safety and performance criteria
- It holds FL #40297 certification for +50/-50 psf 8080 18ga Pair
- Compliant with ADA (Americans with Disabilities Act) and ICC/ANSI 117.1 for accessible and usable buildings
Trust the 6400V Surface Vertical Rod Exit Device for superior functionality and peace of mind.
6400V Architectural Submittal Sheet
6T Thumb piece -trim
Challenging
Recommended for Experienced Installers
Company Info
Resources
Why Buy From Us?
Huge Inventory
Huge Inventory
No Hassle Returns
Satisfaction
Guaranteed
Guaranteed
News & Updates
Sign up to get the latest on sales, new releases and more …
