Cal-Royal 7700 Panic Device Accessories - RIGID LEVER ESCUTCHEON
$150.00
CONSTRUCTION
• Rigid, non-clutch mechanism
• Double heavy duty spring support to prevent
sagging and enhance operation
• Grade 1, thru-bolted design. Non-handed design.
Easily field reversible
• Hardened steel heavy duty tailpiece. Available
for fire and non-fire rated rim and vertical rod exit
devices
• Standard 6-Pin Schlage “C” Mortise Cylinder
included
DOOR THICKNESS
Standard 1 ¾”. For 2 ¼” thick door use additional
Part # TAIL3
ESCUTCHEON DIMENSIONS
2 ¾” width X 10 ¼” length. Lever length: 4 ¾”.
Fits and covers 2 ⅛” 161 cutout
Installation Challenge Level
Challenging
Recommended for Experienced Installers, but not rocket science.
Cal-Royal A7700 Accessories -Outside Trim CLUTCH CYLINDRICAL LEVER
$121.00
COMPATIBLE WITH: Cal-Royal 7700 Series Exit Device, Cal-Royal 5000 Series Exit Device
Non-Handed Grade 1 (Clutch Style)
Cylindrical body hardened steel heavy duty tailpiece. For 1 ¾” and 2 ¼” doors.
Prefix “THI” before Part # for 2 ¼” door thickness.
Available for fire and non-fire rated rim and vertical rod exit devices.
Rose diameter 3 ½”, lever length 4 ¾”. Fits and covers 161 cutout.
Finishes: US32D, US26D
INCLUDES GRADE 304SS LEVER AND ROSE
Installation Challenge Level
Challenging
Recommended for Experienced Installers, but not rocket science.
Cal-Royal Mechanical Easy Code Change Trim only
$267.00
Cal-Royal Mechanical Easy Code Change EXIT DEVICE TRIM ONLY for Rim and Surface Vertical Rods
Outside Trim for CAL-ROYAL 2200, 6600, 7700 and 9800 Series Rim and Surface Vertical Rods
Operated by lever from outside and when push pad is depressed, except outside has to enter a pre-programmed code on the keypad in order to retract the latch upon turning the lever. For use with 2200, 6600, 7700 and 9800 Series Rim and Surface Vertical Rods.
Default Function: Storeroom
Optional Function: Passage Mode
Finish: Satin Chrome (US26D)
Door Thickness: 1 3⁄4” - 2”
Catalogue page-crcode200-series
Installation Challenge Level
Challenging
Recommended for Experienced Installers.
PDQ 4200 Exit Device Trim - Grip Pull with Thumbpiece
$84.00
This PDQ 4200 Series trim component provides grip pull with Thumbpiece for PDQ 4200 Series Rim and Surface Vertical Rod Exit Devices.
Includes standard Schlage SC1 cylinder.
Finishes
Satin Stainless Steel 630/US32D
Installation Challenge Level
Challenging Recommended for Experienced Installers, but not rocket science.
PDQ 4200 Exit Device Trim - Lever
$81.00
This 4200 Series trim component provides an outside lever for PDQ 4200 Series Rim and Surface Vertical Rod Exit Devices.
Includes standard Schlage SC1 cylinders.
Finishes
Satin Chrome Plated 626/US32D
Installation Challenge Level
Challenging
Recommended for Experienced Installers, but not rocket science.
PDQ 6300 Exit Device Trim - Grip Pull with Thumbpiece
$254.00
This PDQ 6200 Series trim component provides grip pull with thumbpiece for PDQ 6200 Series Rim and Surface Vertical Rod Exit Devices.
Includes standard Schlage SC1 cylinder.
FUNCTION
- Entrance by thumb piece. Key locks or unlocks thumb piece (classroom thumb piece)
Finishes
Satin Stainless Steel 630/US32D
Installation Challenge Level
Challenging
Recommended for Experienced Installers, but not rocket science.
PDQ 6300 Exit Device Trim - Lever
$134.00
This 6300 series trim component provides an outside lever for PDQ 6200 Series Rim and Surface Vertical Rod Exit Devices.
Includes standard Schlage SC1 cylinder.
Finishes
Satin Chrome Plated 626/US32D
Installation Challenge Level
Challenging
Recommended for Experienced Installers, but not rocket science.
