Door Closers
Premium Quality without the Premium Price, PDQ Door Closers meet the requirements of the Buy American Act.
Standard and Heavy-Duty Commercial Door Closers, Hold Open Arms, and Drop Plates from PDQ Manufacturing in Pennsylvania.
PDQ 3101 Commercial Door Closer with Hold Open Arm
$164.00
The PDQ 3100 Series is a traditional style door control for use on commercial door applications.
Hold Open Arms for PDQ Door Closers fix the door in an open position. They are helpful when the entryway needs to accommodate high traffic over time or when pedestrians are carrying objects and need an unobstructed path. Applications might include store front doors, glass front entrances, interior shopping mall doors and other similar applications. An important note: hold open arms can only be used on non-fire rated doors. Friction hold open arms are available in all three mounts—regular, top jamb and parallel arm. Friction hold open arms allow the door to be automatically placed in the hold open position until the user puts force on the door to disengage the friction hold and cause the door to close. A friction hold open arm can be used with the standard template of the door closer; it’s a simple replacement.
Features
- Full Rack and Pinion Construction
- Cast Aluminum Body
- Hold Open Arm
Specs
- Adjustment:
- Adjustable controlled closing
- Separate hydraulic backcheck standard
- Separate sweep, latch, backcheck intensity and backcheck positioning valves
- Mounting:
- Fasteners for wood and metal doors and frames
- Sex nuts and bolts standard / Retrofits LCN 4040 Series
- Certification:
- UL and ULC listed
- Complies with UL 10C and UBC 7.2 (1997) Certified to ANSI A156.4 Grade 1
- Warranty: Twenty-five (25) year limited warranty
Finishes
Aluminum 689-SP28
Duro Bronze 695-SP313
Installation Challenge Level
Challenging
Recommended for Experienced Installers. Read more about Door Closers.
Manufacturer Video
PDQ 7101 Heavy-Duty Door Closer with Hold Open Arm
$255.00
The PDQ 7100 Series is an extra heavy-duty door closer which retrofits the LCN 4040 Series.
Hold Open Arms for PDQ Door Closers fix the door in an open position. They are helpful when the entryway needs to accommodate high traffic over time or when pedestrians are carrying objects and need an unobstructed path. Applications might include store front doors, glass front entrances, interior shopping mall doors and other similar applications. An important note: hold open arms can only be used on non-fire rated doors. Friction hold open arms allow the door to be automatically placed in the hold open position until the user puts force on the door to disengage the friction hold and cause the door to close.
Features
- Door Saver Hold Open Arm
- Full Rack and Pinion Construction
- Cast Iron Closer Body
- Forged Steel Main Arm
- Architectural Cover
Specs
- Adjustment:
- Adjustable size 1-6
- Can meet 5 lbf. and 8.5 lbf. barrier free force ADA requirements
- Adjustable controlled closing
- Separate hydraulic backcheck standard
- Backcheck positioning valve standard
- Separate sweep, latch, backcheck intensity and backcheck positioning valves
- Optional delayed action (in lieu of backcheck)
- Mounting:
- Non-handed
- Fasteners for wood and metal doors and frames
- Sex nuts and bolts standard
- Retrofits LCN 4040 Series
- Certification:
- UL and ULC listed
- Complies with UL 10C and UBC 7.2 (1997) Certified to ANSI A156.4 Grade 1
- Warranty: Twenty-five (25) year limited warranty
Finishes
Aluminum 689/SP28
Duro Bronze 695/SP31
Installation Challenge Level
Challenging
Recommended for Experienced Installers. Read more about Door Closers.
PDQ 3101 Commercial Door Closer with Door Saver Hold Open Arm
$164.00
The PDQ 3100 Series is a traditional style door control for use on commercial door applications.
Hold Open Arms for PDQ Door Closers fix the door in an open position. They are helpful when the entryway needs to accommodate high traffic over time or when pedestrians are carrying objects and need an unobstructed path. Applications might include store front doors, glass front entrances, interior shopping mall doors and other similar applications. The Door Saver Hold Open Arm saves the door from opening too far. An important note: hold open arms can only be used on non-fire rated doors.
Features
- Full Rack and Pinion Construction
- Cast Aluminum Body
- Door Saver Hold Open Arm
Specs
- Adjustment:
- Adjustable controlled closing
- Separate hydraulic backcheck standard
- Separate sweep, latch, backcheck intensity and backcheck positioning valves
- Mounting:
- Fasteners for wood and metal doors and frames
- Sex nuts and bolts standard / Retrofits LCN 4040 Series
- Certification:
- UL and ULC listed
- Complies with UL 10C and UBC 7.2 (1997) Certified to ANSI A156.4 Grade 1
- Warranty: Twenty-five (25) year limited warranty
Finishes
Aluminum 689/SP28
Duro Bronze 695/SP313
Installation Challenge Level
Challenging
Recommended for Experienced Installers. Read more about Door Closers.
Manufacturer Video
PDQ 7101 Heavy-Duty Door Closer with Door Saver Hold Open Arm
$285.00
The PDQ 7100 Series is an extra heavy-duty door closer which retrofits the LCN 4040 Series.
Hold Open Arms for PDQ Door Closers fix the door in an open position. They are helpful when the entryway needs to accommodate high traffic over time or when pedestrians are carrying objects and need an unobstructed path. Applications might include store front doors, glass front entrances, interior shopping mall doors and other similar applications. The Door Saver Hold Open Arm saves the door from opening too far. An important note: hold open arms can only be used on non-fire rated doors.
Features
- Door Saver Hold Open Arm
- Full Rack and Pinion Construction
- Cast Iron Closer Body
- Forged Steel Main Arm
- Architectural Cover
Specs
- Adjustment:
- Adjustable size 1-6
- Can meet 5 lbf. and 8.5 lbf. barrier free force ADA requirements
- Adjustable controlled closing
- Separate hydraulic backcheck standard
- Backcheck positioning valve standard
- Separate sweep, latch, backcheck intensity and backcheck positioning valves
- Optional delayed action (in lieu of backcheck)
- Mounting:
- Non-handed
- Fasteners for wood and metal doors and frames
- Sex nuts and bolts standard
- Retrofits LCN 4040 Series
- Certification:
- UL and ULC listed
- Complies with UL 10C and UBC 7.2 (1997) Certified to ANSI A156.4 Grade 1
- Warranty: Twenty-five (25) year limited warranty
Finishes
Aluminum 689/SP28
Duro Bronze 695/SP313
Installation Challenge Level
Challenging
Recommended for Experienced Installers. Read more about Door Closers.
PDQ 3101 Commercial Door Closer Accessory: Parallel Arm Drop Plate
$41.00
Required for PDQ 3101 Door Closer parallel arm mount with limited top door rail.
Finishes
Aluminum 689/SP28
Duro Bronze 695/SP313
Installation Challenge Level
Easy
If you can read instructions and use basic tools, you can install this. Read more about Door Closers.
INSTRUCTIONS & TEMPLATES
PDQ 7101 Heavy-Duty Door Closer Accessory: Parallel Arm Drop Plate
$41.00
Required for PDQ 7101 Door Closer parallel arm mount with limited top door rail.
Finishes
Aluminum 689/SP28
Duro Bronze 695/SP313
Installation Challenge Level
Easy
If you can read instructions and use basic tools, you can install this. Read more about Door Closers.
INSTRUCTIONS & TEMPLATES
PDQ 3101 Commercial Door Closer Accessory: Hold Open Arm
$88.00
Hold Open Arms for PDQ Door Closers fix the door in an open position. They are helpful when the entryway needs to accommodate high traffic over time or when pedestrians are carrying objects and need an unobstructed path. Applications might include store front doors, glass front entrances, interior shopping mall doors and other similar applications. An important note: hold open arms can only be used on non-fire rated doors. Friction hold open arms are available in all three mounts—regular, top jamb and parallel arm. Friction hold open arms allow the door to be automatically placed in the hold open position until the user puts force on the door to disengage the friction hold and cause the door to close. A friction hold open arm can be used with the standard template of the door closer; it’s a simple replacement.
Finishes
Aluminum 689/SP28
Duro Bronze 695/SP313
Installation Challenge Level
Easy
If you can read instructions and use basic tools, you can install this. Read more about Door Closers.
PDQ 7101 Heavy-Duty Door Closer Accessory: Hold Open Arm
$87.50
Hold Open Arms for PDQ Door Closers fix the door in an open position. They are helpful when the entryway needs to accommodate high traffic over time or when pedestrians are carrying objects and need an unobstructed path. Applications might include store front doors, glass front entrances, interior shopping mall doors and other similar applications. An important note: hold open arms can only be used on non-fire rated doors. Friction hold open arms are available in all three mounts—regular, top jamb and parallel arm. Friction hold open arms allow the door to be automatically placed in the hold open position until the user puts force on the door to disengage the friction hold and cause the door to close. A friction hold open arm can be used with the standard template of the door closer; it’s a simple replacement.
Finishes
Aluminum 689/SP28
Duro Bronze 695/SP313
Installation Challenge Level
Easy
If you can read instructions and use basic tools, you can install this. Read more about Door Closers.
PDQ 3101 Commercial Door Closer Accessory: Door Saver Hold Open Arm
$99.00
Hold Open Arms for PDQ Door Closers fix the door in an open position. They are helpful when the entryway needs to accommodate high traffic over time or when pedestrians are carrying objects and need an unobstructed path. Applications might include store front doors, glass front entrances, interior shopping mall doors and other similar applications. The Door Saver Hold Open Arm saves the door from opening too far. An important note: hold open arms can only be used on non-fire rated doors. Thumb-turn or twist-turn hold open arms are used in parallel arm, top jamb or regular mount applications. You have to know the maximum degree of door swing and the desired hold-open angle—is it 120 degrees? 90 degrees? The hold open angle will impact the templating when the door closer is installed, so a hold-open angle needs to be determined before installation occurs in the field.
Finishes
Aluminum 689/SP28
Duro Bronze 695/SP313
Installation Challenge Level
Easy
If you can read instructions and use basic tools, you can install this. Read more about Door Closers.
PDQ 7101 Heavy-Duty Door Closer Accessory: Door Saver Hold Open Arm
$99.00
Hold Open Arms for PDQ Door Closers fix the door in an open position. They are helpful when the entryway needs to accommodate high traffic over time or when pedestrians are carrying objects and need an unobstructed path. Applications might include store front doors, glass front entrances, interior shopping mall doors and other similar applications. The Door Saver Hold Open Arm saves the door from opening too far. An important note: hold open arms can only be used on non-fire rated doors.
Finishes
Aluminum 689/SP28
Duro Bronze 695/SP313
Installation Challenge Level
Easy
If you can read instructions and use basic tools, you can install this. Read more about Door Closers.
Cal-Royal 900 Series Door Closer
$85.00
Optional arms are now PACKED TOGETHER with door closers ( For CR441, N900PBF, CR801/CR801S, and 300PCOV/300PBFCOV )
Meets and exceeds ANSI Standard 156.4 Grade 1
Optional arms are still available individually
Features
● Cal-Royal’s Finest Hydraulic Door Closer Series
Meeting The Highest Industry Standards Grade 1
● Heavy-Duty Full Feature Multi-Size Commercial
Door Closer For Use In Office Buildings, Shopping
Center And Other Commercial Buildings
● Non-Sized, 1 thru 6 FACTORY PRESET SIZE 3
● Door Weights: 30-260 lbs (All Models)
Specs
● Adjustable Closing and Latching Speed by Two Separate Regulating Valves
● Optional Adjustable Delayed Action For Handicapped or Elderly
Finishes
Aluminum 689/SP28
Duro Bronze 695/SP31
Warranty
Lifetime Warranty
Installation Challenge Level
Challenging
Recommended for Experienced Installers. Read more about Door Closers.
TEMPLATES
- Template - 900 Series Parallel Arm Application
- Template - 900 Series Regular Arm Application
- Template - 900 Series Top Jamb Application Left
INSTALLATION INSTRUCTIONS
- Installation Instructions - 900SPAS, 900HOSRPS
- Installation Instructions - 901-902 Hold Open Arm
- Installation Instructions - 900SPRING, 900HOSRPRING
- Installation Instructions - 900PBF Door Closer
- Installation Instructions - Track- 900 Door Closer
CATALOG PAGE
