3801 Series Straight Grab Bar

• Straight Grab Bar
• Snap Flange - cover snaps over mounting flange to conceal screws
• Type 304 Stainless Steel - Satin Finish
• Surface Mounted
• 18 gauge tubing with 1-1/2" Outside Diameter [Ø38]
• Concealed mounting flange of 3-1/8" [79] O.D. with 2 screw holes and 3 locking dimples
• Cover is type 304 stainless steel with a satin finish and 22 gauge, 3-3/16" [81] diameter

Type
Straight Grab Bar

Material
Type 304 Stainless Steel

Construction
18 gauge tubing with 1-1/2" Outside Diameter [Ø38]

Mounting
Surface Mounted

Mounting Flange
3-1/8" [79] O.D. with 2 screw holes and 3 locking dimples

Mounting Capacity
ASI grab bars are designed to meet and exceed 2010 ADA Accessibility Standards and ANSI A117.1 that fabricated product shall be of adequate strength to support a load in excess of 250 pounds (113.4 kg). Mounting to the wall is a critical part of the system to meet this requirement. The fastener system must be adequately sized to withstand the shear, tension or pullout, and torsion loads generated by the maximum loading.

• 42" / 10-3801-42
• 36" / 10-3801-36
• 18" / 10-3801-18

Stainless Steel
Satin finish, unless otherwise noted.

Stainless Steel washroom accessory products require regular surface cleaning, much the same as stainless steel sinks, pots and pans and eating utensils.

As long as a regular cleaning schedule is followed, the best method is cleaning with a soft clean rag moistened with a mild detergent, followed by a water-moistened clean rag and then a dry rag.

For a “new" look, surfaces can be wiped with lemon oil applied by a soft polishing cloth to maintain sheen.

Stainless Steel should be protected against muriatic acid and caustic or abrasive materials, and harsh cleaning detergents [with pH outside the range 7 ± 1.5].

In the event such agents cause discoloration, polishing with a stainless steel cleaner such as 3M™ Stainless Steel Cleaner & Polish® and a soft cloth on bright or mirror finishes, or for satin finish surfaces the Stainless Steel cleaner and 3M™ Scotch Brite® pad either blue (less aggressive) or green (more aggressive) is recommended.

Use grab bar as template to mark mounting holes locations and pre-drill holes. Install bar using two (2) #10 selfthreading flat head or oval head screws (by others) or other fastener system (by others) to suit conditions for each flange.

Appropriate anchoring and backing must be provided in accordance with local building codes or as specified on Architects Plans prior to wall finishing.

For compliance with 2010 ADA Accessibility Standards install unit so that the top of the grab bar is 33" [840] minimum Above Finished Floor (AFF) to 36" [915] maximum AFF.

Anchors are available from ASI and must be specified separately for each grab bar style scheduled (see 3900 series).

• Product Care & Maintenance
• Grab Bar Configurations

Technical Data Sheets

• 42" / 10-3801-42 – Technical Data Sheet
• 36" / 10-3801-36 – Technical Data Sheet
• 18" / 10-3801-18 – Technical Data Sheet
